English |

21

If the laser line is intended to appear at a certain height on the wall, this height should be
marked in advance. Then position the measuring tool on the wall so that the height mark-
ing is situated in the centre of the marking aid

(1)

 of the measuring tool.

Removing the measuring tool from the substrate (see figure

A):

Carefully remove the measuring tool from the substrate as shown in the image. Removing
the measuring tool from a delicate surface too quickly can damage the substrate.
After removing the tool, check that the gel pad

(14)

 is still clean. If it has become dirty, it

should be cleaned as necessary.
Place the protective cap

(15)

 on the gel pad

(14)

 and turn it clockwise to lock it in place.

The measuring tool should only ever be transported and stored with the protective cap
attached. If the gel pad becomes dirty, it will lose its adhesive strength.

Attaching with the pin pad (see figure B)

The substrate must be dry and firm.
To ensure the attachment is secure, position the measuring tool with the pin pad

(7)

 on

the substrate so that the pins are diagonally aligned to the measuring tool. It is not re-
commended to attach with pins horizontally or vertically to the measuring tool.
Insert the pins into the recesses on the pin pad. Ensure that the pins are securely affixed
to the substrate.
If the laser line is intended to appear at a certain height on the wall, this height should be
marked in advance. Then position the measuring tool on the wall so that the height mark-
ing is situated in the centre of the marking aid

(1)

 of the measuring tool.

Always remove the measuring tool once you have finished taking a measurement, or if
the substrate is being worked on in some manner (e.g. drilling, screwdriving, or hammer-
ing).

Operation

Starting Operation

u

Protect the measuring tool from moisture and direct sunlight.

u

Do not expose the measuring tool to any extreme temperatures or variations in
temperature.

 For example, do not leave it in a car for extended periods of time. In

case of large variations in temperature, allow the measuring tool to adjust to the ambi-
ent temperature before putting it into operation. The precision of the measuring tool
may be compromised if exposed to extreme temperatures or variations in temperat-
ure.
