24

 | English

Rectifying Errors

Problem

Corrective measures

The light-up ring

(3)

 flashes yellow 3 times

during operation, then the measuring tool
switches off.

Replace the battery.

The measuring tool is not within the operat-
ing temperature range specified in the
technical data and switches itself off.

Allow the measuring tool to reach the cor-
rect temperature and switch it back on
once it is back within the operating temper-
ature range.

The gel pad

(14)

 does not affix properly.

– Check whether the substrate is suitable

for the gel pad.

– If the gel pad is dirty, it should be

cleaned.

– If the gel pad is damaged, it should be

replaced.

The laser line is not vertical or horizontal as
required after it has been levelled in.

Calibrate the laser line.

Maintenance and Service

Maintenance and Cleaning

Keep the measuring tool clean at all times.
Never immerse the measuring tool in water or other liquids.
Wipe off any dirt using a damp, soft cloth. Do not use any detergents or solvents.
The areas around the outlet aperture of the laser in particular should be cleaned on a reg-
ular basis. Make sure to check for lint when doing this.

Cleaning the Gel Pad

Clean the gel pad

(14)

 whenever it has become contaminated with dust or other

particles, or if its adhesive strength has been reduced.

u

Only wash the gel pad when it has been detached from the tool.

 The measuring

tool itself must not be washed or submerged in water.

To detach the gel pad, turn the gel pad holder

(13)

 anticlockwise and take off the holder.

Rinse the gel pad

(14)

 with water. Wash it as necessary using a common household neut-

ral soap or a detergent. Do not use any cleaning agents that contain alcohol or solvents. If
necessary, the protective cap

(15)

 should also be cleaned.
