You are advised to clean the appliance before switching it on for

the first time,  see “Cleaning”.

Switching the appliance on and off

,

Fig.

A1

W

  Switching on:

Press the on/off button

3

 so that the tempera-

ture display lights up/flashes.

-  At start up and as long as the unit is warm, the room tempera-

ture is shown first until the desired temperature is reached.

-  The Lighting* will light up when the door is open.

W

  Switching off:

Press the on/off button for approx. two sec-

onds so that the temperature display goes out.

Setting the temperature

W

  To reduce the temperature:

  Press the DOWN button

2

.

W

  To increase the temperature:

  Press the UP button

2

.

-  While you are entering the temperature, the

set temperature

will flash

 on the display.

-  When you press the temperature setting buttons for the first

time, the

most recent setting

 (known as the "

refer-ence

setting

") is displayed.

-  You can change the settings in increments of 1°C by briefly

pressing the buttons again.  If the buttons are held down the

temperature setting will change faster.

-  Approx. 5 seconds after the last button was pressed, the

electronic switches over automatically and the actual cooling

temperature (= actual value) is shown.

-  The temperature can be set at between 2 °C and 9 °C.

     Whether you can obtain the lowest temperature depends on

where the appliance is positioned (if it is located in an area

with a high ambient temperature it will not reach the lowest

temperature).

W

  Recommended temperature settings:

-    For the

refrigerator compartment:

 5 °C

For appliances with

freezer compartment*

the following is true:

-  If frozen food is stored and low compartment temperatures are

guaranteed, the temperature control setting between 2 °C and

5 °C is recommended.

-  When the ambient temperatures are below 1 °C, the winter

heating of the device switches on automatically.

Note:

 Please note that the temperature inside the appliance is

affected by the frequency with which the door is opened, how full

the appliance is and the room temperature at the place where the

appliance is installed.

SuperCool*

,

Fig.

 A1/

5

SuperCool is particularly recommended for when you want to

cool large quantities of freshly stored food or drinks as quickly as

possible. The refrigeration temperature then decreases the value

of the coldest temperature performance.

W

  Switching On and Off:

 Briefly press SuperCool button

5

,

lighting up the appropriate LED (dark= off).

Note:

 SuperCool consumes more energy.

  However, after about 6 seconds the electronics automatically

switch back to energy-saving normal operation.

Putting into operation

and control elements

The interior light

switches off automatically when door is open for more than ap-

prox. 15 minutes. If the lamp does not light up when the door is

opened briefly, but the temperature setting display does, the light

bulb may be defective.

Replacing the bulb:

W

  Light-bulb specifications:

 max.15 W, power supply and

voltage should match the details on the rating plate. Only use

light bulbs with the same dimensions, fitting: E 14.

W

  Switch off the appliance.

 Disconnect mains plug or trip or

unscrew fuse.

W

  Push the sides 1 of the lamp cover together according to Fig.

F1

, unlatch and detach at rear 2.

W

  Replace the light bulb according to Fig.

F2.

W

  Attach the cover at the rear again and lock into place on sides.

Refrigerator compartment

Temperature setting display

,

Fig.

A1/

1

In normal operation, the actual cooling temperature is shown.

The display will flash:

-  if you change the temperature

W

  If "

F 1

"

to "

F 5

" appears in the display, the appliance has

a fault.  Consult the customer service department indicat-ing

the fault number displayed as this will tell the techni-cian what

kind of irregularity has occurred.

-  The illuminated temperature setting display indicates opera-

tion of the appliance.

Additional functions

In set-up mode you can set the

child-proof lock

 and adjust the

brightness of the display*:

Activating set-up mode:

W

  Press SuperFrost button for approx. 5 secs - the SuperFrost

button flashes - the display shows

c

 for

child-proof lock.

  Note: the value to be altered flashes.

W

  Select the required function by pressing the Up/Down button:

  c

=

 child-proof lock

 or

h

=

 brightness.

W

  Now select/acknowledge function by pressing Super-

Frost button briefly:

•  For

 c

=

 child-proof lock

, press the Up/Down but-

ton to select c

1

= child-proof lock

 on

or

c

0

 = child-proof lock

off

and acknowledge with the

SuperFrost button. When the symbol

6

 is lit, the child-proof

lock is activated.

•  For

h

=

 brightness

,

press Up/Down button to

select h

1

=

minimum

 to

h

5

 =

 maximum

 brightness

and acknowledge with the SuperFrost button.

Exit set-up mode:

W

  To exit the set-up mode, press the On/Off button; after 2 mins.

the electronic system switches over automatically.

-  The normal operating mode is activated again.

-  Temperature ranges are allocated to the individual LEDs.

They indicate the selected setting of the refrigerating/ freez

-

ing temperature.

*

 according to Model and design

11

GB
