u

Wipe dry the appliance and items of equipment.

u

Connect the appliance and switch it on again.

u

Switch on SuperFrost (see 5.8) .

When the temperature is sufficiently cold:

u

Put the food back inside.

6.3 Cleaning the IceMaker*

Fig. 7

The IceMaker has to be switched on.

u

Pull out the drawer and remove the ice cubes.

u

Clean  the  drawer  with  warm  water  and  mild  washing-up

liquid.

u

When the drawer is pulled out, hold down the On/Off button

(about 10 seconds).

w

After  about  1  s  the  LED  goes  out,  the  IceMaker  is  switched

off.

w

After about 10 s the LED flashes for about 60 s.

u

Slide in the drawer while the LED is flashing.

w

The ice-cube tray of the IceMaker turns to a skew position.

u

Remove the drawer.

u

Clean  the  ice  cube  tray  with  warm  water.  If  necessary,  use

mild washing-up liquid. Then rinse.

Switch the IceMaker on again.

u

Press the ON/OFF button until the LED shines, then slide in

the drawer.

w

The IceMaker starts producing ice cubes.

If washing-up liquid was used:

u

throw away the first three loads of ice cubes to get rid of any

remaining washing-up liquid.

6.4 Customer service

First  check  whether  you  can  correct  the  fault  yourself  by  refer-

ence to the list (see Malfunction). If this is not the case, please

contact  the  customer  service  whose  address  is  given  in  the

enclosed customer service list.

WARNING

Risk of injury if repair work is not carried out professionally!

u

Have  any  repairs  and  action  -  not  expressly  specified  -  on

the  appliance  and  mains  cable  carried  out  by  service

personnel only. (see Maintenance)

u

Read  the  appliance

designation

Fig.  8  (1),  service

No.

  Fig.  8  (2)  and

serial  No.

  Fig.  8  (3)

off  the  type  plate

located  inside  the

appliance on the left-

hand side.

Fig. 8

u

Notify  the  customer  service,  specifying  the  fault,  appliance

designation

  Fig.  8  (1),  service  No.  Fig.  8  (2)  and  serial  No.

Fig. 8 (3).

w

This will help us to provide you with a faster and more accu-

rate service.

u

Keep  the  appliance  closed  until  the  customer  service

arrives.

w

The food will stay cool longer.

u

Pull out the mains plug (not by pulling the connecting cable)

or switch off the fuse.

7 Malfunction

Your  appliance  is  designed  and  manufactured  for  a  long  life

span  and  reliable  operation.  If  a  malfunction  nonetheless

occurs  during  operation,  check  whether  it  is  due  to  a  handling

error.  In  this  case  you  will  have  to  be  charged  for  the  costs

incurred,  even  during  the  warranty  period.  You  may  be  able  to

rectify the following faults yourself:
Appliance does not work.

→

The appliance is not switched on.

u

Switch on the appliance.

→

The power plug is not properly inserted in the wall socket.

u

Check power plug.

→

The fuse of the wall socket is not in order.

u

Check fuse.

The compressor runs for a long time.

→

The compressor switches to a low speed when little cold is

needed. Although the running time is increased as a result,

energy is saved.

u

This is normal in energy-saving models.

→

SuperFrost is activated.

u

The  compressor  runs  for  longer  in  order  to  rapidly  cool  the

food. This is normal.

Excessive noise.

→

Speed-controlled*  compressors  may  produce  varying

running noise due to different speed steps.

u

The sound is normal.

A bubbling and gurgling noise.

→

This noise comes from the refrigerant flowing in the refriger-

ation circuit.

u

The sound is normal.

A quiet clicking noise.

→

The  noise  is  produced  whenever  the  refrigeration  unit

(motor) automatically switches on or off.

u

The sound is normal.

A hum. It is briefly a little louder when the refrigeration

unit (the motor) switches on.

→

The  refrigeration  increases  automatically  when  the  Super-

Frost, function is activated, fresh food has just been placed

in the appliance or the door has been left open for a while.

u

The sound is normal.

→

The ambient temperature is too high.

u

Solution: (see 1.2)

A low hum.

→

The sound is produced by air flow noise of the fan.

u

The sound is normal.

Flow sound at the soft stop mechanism.

→

The  noise  is  produced  when  the  door  is  opened  and

closed.

u

The sound is normal.

The temperature display indicates:

F0

 to

F5

.

→

There is a fault.

u

Contact the customer service (see Maintenance).

The temperature display indicates:

nA

→

The freezer temperature rose too high over the last hours or

days due to a power failure or power interruption. When the

power  interruption  is  over,  the  appliance  will  continue  to

operate in the last temperature setting.

u

alarm button

Fig. 2 (6)Press

Malfunction

8
