w

When the button is pressed the first time, the previous value

is indicated in the temperature display.

u

To  change  the  temperature  in  1  °C  steps:  briefly  press  the

button.

-or-

u

To  change  the  temperature  continuously:  hold  down  the

button.

w

The value is displayed flashing during the setting operation.

w

The  actual  temperature  is  displayed  about  5  s  after  the  last

press of a button. The temperature slowly adjusts to the new

value.

5.8 SuperFrost

With  this  function  you  can  freeze  fresh  food  quickly  through  to

the  core.  The  appliance  operates  with  maximum  refrigeration.

The noise of the refrigeration unit may be temporarily louder as

a result.
The  maximum  amount  of  fresh  food  which  can  be  frozen  in  24

h  is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".  This  amount  varies  according  to  the  model  and  climate

rating.
You do not have to activate SuperFrost in the following cases:

-

when placing frozen food in the freezer

-

when freezing up to about 2 kg fresh food daily

5.8.1 Freezing with SuperFrost

u

Briefly press the SuperFrost button

 Fig. 2 (5) once.

w

The SuperFrost button

 Fig. 2 (5) shines.

w

The  freezer  temperature  drops,  the  appliance  operates  with

maximum refrigerating performance.

For a small amount of food:

u

wait about 6 h.

u

Place the fresh food in the top drawers.

For the maximum amount of food:

u

wait about 24 h.

u

Place  wrapped  food  straight  on  the  shelves  and,  once

frozen, put it into the drawers.

w

SuperFrost  is  automatically  deactivated.  Depending  on  the

quantity  placed  inside,  after  30  h  at  the  earliest,  65  h  at  the

latest.

w

Freezing is concluded.

w

The SuperFrost button

 Fig. 2 (5) is dark.

w

The  appliance  continues  to  operate  in  the  energy-saving,

normal mode.

5.9 Drawers

Note

The  energy  consumption  increases  and  the  cooling  perform-

ance decreases if there is insufficient ventilation.

For appliances with NoFrost:

u

Leave the bottom drawer in the appliance!

u

Always keep the air slits of the fan free at the rear wall!

Fig. 3

Fig. 4

u

To store frozen food directly on the shelves: raise the drawer

at the back and pull it out forwards.

5.10 Shelves

u

To  remove  the  shelf:  lift  up  at  the

front and pull out.

u

To put the shelf back: simply push

in as far as it will go.

5.11 VarioSpace

Apart  from  being  able  to  remove

the  drawers,  you  can  also

remove  the  shelves,  creating

space  for  large  items  of  frozen

food. Poultry, meat, large pieces

of  game  and  high  bakery  prod-

ucts  can  be  frozen  in  one  piece

and prepared.

u

The  maximum  load  for  the  top  drawer  is  5  kg  and  for  the

other drawers 25 kg each.

u

The shelves can each be loaded with 35 kg of frozen food.

5.12 Pull-out rails

u

To  remove  the  pull-out  rail:  press

down  the  front  snap-fit  devices  and

push the pull-out rail away, sideways

and backwards.

u

To  fit  the  pull-out  rail:  engage  at  the

back and snap into place at the front.
