5.13 Information system

Fig. 5

(1) Ready-made meals, ice

cream

(4) Sausages, bread

(2) Pork, fish

(5) Game, mushrooms

(3) Fruit, vegetables

(6) Poultry, beef/veal

The  figures  indicate  the  storage  time  in  months  for  several

types  of  frozen  food  in  each  case.  Storage  times  given  are

guide times.

5.14 Cold storage accumulators

The  cold  storage  accumulators  prevent  the  temperature  from

rising too fast in the event of power failure.

5.14.1 Using cold storage accumulators

u

Place  the  cold  storage  accu-

mulators  in  the  top  freezer

compartment to save space.

u

Place  the  frozen  cold  storage

accumulators  on  the  frozen

food in the upper front area of

the freezer compartment.

5.15 IceMaker*

The  IceMaker  is  in  the  fourth  drawer  from  the  top.  The  drawer

is marked "IceMaker".
Make certain that the following conditions are met:

-

The appliance is level.

-

The appliance is connected.

-

The IceMaker is connected to the water supply.

5.15.1 Switching on the IceMaker*

Fig. 6

u

Pull out the drawer.

u

Press the On/Off button

 Fig. 6 (1) so that the LED Fig. 6 (2)

shines.

u

Push in the drawer.

Note

u

The  IceMaker  produces  ice  cubes  only  if  the  drawer  is  fully

closed.

5.15.2 Producing ice cubes*

The  production  capacity  depends  on  the  freezer  temperature.

The  lower  the  temperature,  the  more  ice  cubes  can  be

produced in a specific period.
The ice cubes drop from the IceMaker into the drawer. When a

certain  filling  level  has  been  reached,  no  further  ice  cubes  are

produced. The IceMaker does not fill the drawer right up to the

brim.

If  large  quantities  of  ice  cubes  are  needed,  the  complete

IceMaker  drawer  can  be  exchanged  for  the  adjacent  drawer.

When  the  drawer  is  closed,  the  IceMaker  automatically  re-

commences production.
Once  the  IceMaker  has  been  switched  on  for  the  first  time,  it

may take up to 24 hours until the first ice cubes are produced.

Note

When  the  appliance  is  used  for  the  first  time  and  if  it  has  been

out of use for a long time, particles may collect in the IceMaker

and/or water conduit.

u

Therefore do not use or consume the ice cubes made in the

first 24 hours.

5.15.3 Switching off the IceMaker*

When  the  IceMaker  is  switched  off,  the  IceMaker  drawer  can

also be used for freezing and storing food.

u

Press  the  On/Off  button  for  about  1  second  until  the  LED

goes out.

u

Clean the IceMaker.

w

This ensures that no water or ice remains in the IceMaker.

6 Maintenance

6.1 Defrosting with NoFrost

The NoFrost system automatically defrosts the appliance.
The  moisture  condenses  on  the  evaporator,  is  periodically

defrosted and evaporates.

u

The appliance does not have to be manually defrosted.

6.2 Cleaning the appliance

Before cleaning:

CAUTION

Risk of injury and damage as a result of hot steam!

Hot steam may damage the surfaces and cause burns.

u

Do not use any steam cleaners!

NOTICE

Incorrect cleaning damages the appliance!

u

Do not use cleaning agents in concentrated form.

u

Do not use any scouring or abrasive sponges or steel wool.

u

Do  not  use  any  cleaning  agents  containing  sand,  chloride,

chemicals or acid.

u

Do not use chemical solvents.

u

Do not damage or remove the type plate on the inside of the

appliance. It is important for the customer service.

u

Do  not  pull  off,  bend  or  damage  cables  or  other  compo-

nents.

u

Do  not  allow  any  cleaning  water  to  enter  the  drain  channel,

ventilation grille or electrical parts.

u

Empty the appliance.

u

Pull out the plug.

- Use  soft  cleaning  cloths  and  a  multi-purpose

cleaning agent with neutral pH value.

- Only  use  food  compatible  cleaning  and  care

agents on the inside of the appliance.

Interior:

u

Clean  the  plastic  surfaces,  outside  and  inside,  by  hand

using lukewarm water and a little washing-up liquid.

Items of equipment:

u

Clean items of equipment by hand with lukewarm water and

a little washing-up liquid.

After cleaning:
