5.13 Freezer tray

The freezer tray allows you to freeze berries, herbs, vegetables

and  other  small  items  of  food  without  them  sticking  together.

Items  being  frozen  will  largely  retain  their  shape,  and  it  will  be

easier to remove exactly the right quantity later on.
In addition, you can store the cold storage accumulators in the

freezer tray to save space.

5.13.1 Using the freezer tray

u

Spread  the  items  out  loosely

on the freezer tray.

u

Allow  the  food  to  freeze

through for 10 to 12 h.

u

Transfer  the  frozen  food  to

freezer bags or containers.

u

Store freezer bags or containers in a drawer.

u

To thaw the items, spead them out loosely again.

5.14 Cold storage accumulators

The  cold  storage  accumulators  prevent  the  temperature  from

rising too fast in the event of power failure.

5.14.1 Using cold storage accumulators

u

Place  the  cold  storage  accu-

mulators  in  the  freezer  tray  to

save space.

u

Place  the  frozen  cold  storage

accumulators  on  the  frozen

food in the upper front area of

the freezer compartment.

6 Maintenance

6.1 Manual defrosting

After a long period of operation, a layer of frost or ice can build

up inside the appliance.
The  layer  of  frost  or  ice  builds  up  faster  if  the  appliance  is

opened  often  or  if  the  food  is  warm  when  placed  inside.

However,  a  thick  layer  of  ice  will  increase  the  appliance‘s

energy  consumption.  You  should  therefore  defrost  the  appli-

ance regularly.

CAUTION

Risk of injury and damage as a result of hot steam!

u

Do not use electric heaters or steam cleaners, naked flames

or defrosting sprays for defrosting.

u

Do not remove ice using sharp instruments.

u

Switch on SuperFrost one day before defrosting.

w

The frozen goods are provided with a "cold reserve".

u

Switch off the appliance.

w

The temperature display goes out.

u

Pull out the power plug or switch off the fuse.

u

Place cold storage accumulators on top of the frozen food.

u

If  possible,  put  the  frozen  goods  in  the  freezer  drawer,

wrapped  in  newspaper  or  a  blanket,  and  store  in  a  cool

place.

u

Remove  the  cover

Fig. 10 (1) of the pres-

sure

compensation

valve

  Fig.  10  (2).  The

valve

is

situated

behind  the  lowermost

large drawer.

Fig. 10

u

Place  a  pan  with  hot,  not  boiling

water on a middle shelf.

w

Defrosting is speeded up.

u

Leave the door of the appliance open while defrosting.

u

Remove detached pieces of ice.

u

If  necessary,  pick  up  defrost  water  several  times,  using  a

sponge or cloth.

u

Check whether the pressure compensation valve

 Fig. 10 (2)

is free of ice and dry.

u

Re-attach  the  cover

  Fig.  10  (1)  of  the  pressure  compensa-

tion valve and snap it into place.

u

Clean the appliance (see 6.2) .

6.2 Cleaning the appliance

Before cleaning:

CAUTION

Risk of injury and damage as a result of hot steam!

Hot steam may damage the surfaces and cause burns.

u

Do not use any steam cleaners!

NOTICE

Incorrect cleaning damages the appliance!

u

Do not use cleaning agents in concentrated form.

u

Do not use any scouring or abrasive sponges or steel wool.

u

Do  not  use  any  cleaning  agents  containing  sand,  chloride,

chemicals or acid.

u

Do not use chemical solvents.

u

Do not damage or remove the type plate on the inside of the

appliance. It is important for the customer service.

u

Do  not  pull  off,  bend  or  damage  cables  or  other  compo-

nents.

u

Do  not  allow  any  cleaning  water  to  enter  the  drain  channel,

ventilation grille or electrical parts.

u

Empty the appliance.

u

Pull out the plug.

- Use  soft  cleaning  cloths  and  a  multi-purpose

cleaning agent with neutral pH value.

- Only  use  food  compatible  cleaning  and  care

agents on the inside of the appliance.

u

Regularly clean ventilation grilles.

w

Dust deposits increase energy consumption.

Outside surfaces and interior:

u

Clean  the  plastic  surfaces,  outside  and  inside,  by  hand

using lukewarm water and a little washing-up liquid.

Items of equipment:

u

Clean items of equipment by hand with lukewarm water and

a little washing-up liquid.

After cleaning:

u

Wipe dry the appliance and items of equipment.

u

Connect the appliance and switch it on again.

u

Switch on SuperFrost (see 5.8) .

When the temperature is sufficiently cold:

u

Put the food back inside.
