CAUTION

Risk of injury if the door tips!

u

The  safety  lock

  (1)  has  to  engage  with  the  turn  hinge  at  the

side  so  that  the  bearing  pin  and  therefore  the  door  are

secured.

u

u

Snap the safety lock

 (1) onto the turn hinge again.

u

If necessary, align the door to the appliance housing by way

of the two oblong holes in the turn hinge

 Fig. 4 (4). To do so,

unscrew the middle screw.

WARNING

Risk of injury due to the door dropping out!

If  the  bearing  parts  are  not  screwed  into  place  firmly  enough,

the  door  may  drop  out.  This  may  lead  to  severe  injuries.  What

is  more,  the  door  may  not  close  and  therefore  the  appliance

may fail to cool properly.

u

Screw on the bearing brackets/bearing pins tightly (4 Nm).

u

Check all of the screws and retighten if necessary.

4.4 Insertion into a row of kitchen units

Fig. 8

(1) Stack cabinet

(3) Kitchen cabinet

(2) Appliance

(4) Wall

If  the  appliance  is  inserted  into  a  row  of  kitchen  units  (max.

depth. 580 mm), the appliance can be placed immediately next

to  the  kitchen  cabinet.  The  appliance  projects  150  mm   at  the

sides and 170 mm in the middle of the appliance, in relation to

the front of the kitchen cabinet.

-

The  ventilation  space  under  the  ceiling  has  to  be  at  least

350 cm

2

.

-

The larger the ventilation space, the more energy-saving the

appliance is in operation.

If  the  appliance  is  installed  with  the  hinges  next  to  a  wall

Fig. 8 (4), the distance between appliance and wall has to be at

least  40  mm.  This  corresponds  to  the  projection  of  the  handle

when the door is open.

4.5 Disposing of packaging

WARNING

Danger of suffocation due to packing material and plastic film!

u

Do not allow children to play with packing material.

The packaging is made of recyclable materials:

-

corrugated board/cardboard

-

expanded polystyrene parts

-

polythene bags and sheets

-

polypropylene straps

-

nailed wooden frame with polyethylene panel*

u

Take the packaging material to an official collecting point.

4.6 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The  type  of  current  (alternating  current)  and  voltage  at  the

installation site have to conform with the data on the type plate

(see Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.
It must be easily accessible so that the appliance can

be quickly disconnected from the supply in an emer-

gency.

u

Check the electrical connection.

u

Plug in the power plug.

4.7 Switching on the appliance

u

Press the On/Off button

 Fig. 3 (1).

w

The  appliance  is  switched  on.  The  temperature  display  and

Alarm  symbol

  Fig.  3  (10)  flash  until  the  temperature  is  cold

enough.

Putting into operation

6
