u

To store frozen food directly on the shelves: pull the drawer

forwards and lift it out.

5.4.5 Shelves

u

To  remove  the  shelf:  lift  up  at  the  front

and pull out.

u

To  put  the  shelf  back:  simply  push  in  as

far as it will go.

5.4.6 VarioSpace

Apart from being able to remove the

drawers,  you  can  also  remove  the

shelves,  creating  space  for  large

items  of  frozen  food.  Poultry,  meat,

large  pieces  of  game  and  high

bakery  products  can  be  frozen  in

one piece and prepared.

u

The maximum load of frozen food

for the drawers is 25 kg each and

for the shelves 35 kg each.

5.4.7 Information system*

Fig. 11

(1) Ready-made meals, ice

cream

(4) Sausages, bread

(2) Pork, fish

(5) Game, mushrooms

(3) Fruit, vegetables

(6) Poultry, beef/veal

The  figures  indicate  the  storage  time  in  months  for  several

types  of  frozen  food  in  each  case.  Storage  times  given  are

guide times.

5.4.8 Cold storage accumulators*

The  cold  storage  accumulators  prevent  the  temperature  from

rising too fast in the event of power failure.
Using cold storage accumulators*

u

Place the cold storage accumula-

tors  in  the  top  freezer  compart-

ment to save space.

u

Place  the  frozen  cold  storage

accumulators  on  the  frozen  food

in  the  upper  front  area  of  the

freezer compartment.

6 Maintenance

6.1 Defrosting with NoFrost

The NoFrost system automatically defrosts the appliance.
Refrigerator compartment:
The  defrost  water  evaporates  due  to  the  compressor  heat.

Drops of water on the rear wall are perfectly normal.

u

Regularly  clean  the  drain  opening  to  allow  the  water  to  flow

away (see 6.2) .

Freezer compartment:
The  moisture  condenses  on  the  evaporator,  is  periodically

defrosted and evaporates.

u

The appliance does not have to be manually defrosted.

6.2 Cleaning the appliance

Before cleaning:

CAUTION

Risk of injury and damage as a result of hot steam!

Hot steam may damage the surfaces and cause burns.

u

Do not use any steam cleaners!

NOTICE

Incorrect cleaning damages the appliance!

u

Do not use cleaning agents in concentrated form.

u

Do not use any scouring or abrasive sponges or steel wool.

u

Do  not  use  any  cleaning  agents  containing  sand,  chloride,

chemicals or acid.

u

Do not use chemical solvents.

u

Do not damage or remove the type plate on the inside of the

appliance. It is important for the customer service.

u

Do  not  pull  off,  bend  or  damage  cables  or  other  compo-

nents.

u

Do  not  allow  any  cleaning  water  to  enter  the  drain  channel,

ventilation grille or electrical parts.

u

Empty the appliance.

u

Pull out the plug.

- Use  soft  cleaning  cloths  and  a  multi-purpose

cleaning agent with neutral pH value.

- Only  use  food  compatible  cleaning  and  care

agents on the inside of the appliance.

u

Regularly clean ventilation grilles.

w

Dust deposits increase energy consumption.

Outside surfaces and interior:

u

Clean  the  plastic  surfaces,  outside  and  inside,  by  hand

using lukewarm water and a little washing-up liquid.

NOTICE*

The  stainless  steel  doors  are  provided  with  a  high-quality

surface  coating  and  must  not  be  treated  using  the  accompa-

nying care product.

Otherwise the surface coating will be affected.

u

Wipe  the  coated  door  surfaces  using  a  soft,  clean  cloth

only.  In  case  of  stubborn  dirt,  use  a  little  water  or  a  neutral

cleaning agent. A microfibre cloth can be optionally used.

u

If the stainless steel side walls are dirty, clean them using

a  commercially  available  stainless  steel  cleaning  agent.

Then  evenly  apply  the  accompanying  stainless  steel  care

product, making strokes in the direction of the grain.

u

Wipe  side  walls  with  a  paint  finish  using  a  soft,  clean

cloth  only.  In  case  of  stubborn  dirt,  use  a  little  water  or  a

neutral  cleaning  agent.  A  microfibre  cloth  can  be  optionally

used.

Do  not  apply  stainless  steel  cleaning  agent  to  glass  or  plastic

surfaces to prevent them from being scratched. Darker areas at

the  beginning  and  quite  an  intensive  colour  of  the  stainless

steel surface are normal.*

u

To  clean  the  drain  opening:  remove

any  deposits  with  a  fine  instrument,

e.g. a cotton bud.

Items of equipment:
