The larger the ventilation space, the more energy-saving the

appliance is in operation.

If  the  appliance  is  installed  with  the  hinges  next  to  a  wall

Fig. 9 (4), the distance between appliance and wall has to be at

least  40  mm .  This  corresponds  to  the  projection  of  the  handle

when the door is open.

4.5 Disposing of packaging

WARNING

Danger of suffocation due to packing material and plastic film!

u

Do not allow children to play with packing material.

The packaging is made of recyclable materials:

-

corrugated board/cardboard

-

expanded polystyrene parts

-

polythene bags and sheets

-

polypropylene straps

-

nailed wooden frame with polyethylene panel*

u

Take the packaging material to an official collecting point.

4.6 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The  type  of  current  (alternating  current)  and  voltage  at  the

installation site have to conform with the data on the type plate

(see Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.
It must be easily accessible so that the appliance can

be quickly disconnected from the supply in an emer-

gency.

u

Check the electrical connection.

u

Plug in the power plug.

4.7 Switching on the appliance

u

Press On/Off button

 Fig. 3 (1).

w

The appliance is switched on. The temperature display indi-

cates the set temperature.

5 Control

5.1 Door alarm

If the door is open longer then 60 s, the audible alarm sounds.
The  audible  alarm  is  automatically  silenced  when  the  door  is

closed.

5.1.1 Muting the door alarm

The  audible  alarm  can  be  muted  when  the  door  is  open.  The

sound  switch-off  function  is  active  as  long  as  the  door  is  left

open.

u

Press alarm button

 Fig. 3 (6).

w

The door alarm is silenced.

5.2 Temperature alarm

The audible alarm sounds if the freezer temperature is not cold

enough.
The alarm button flashes at the same time.
The cause of the temperature being too high may be:

-

warm fresh food was placed inside

-

too much warm ambient air flowed in when rearranging and

removing food

-

power failure for some time

-

the appliance is faulty

The  audible  alarm  is  automatically  silenced,  the  alarm  button

Fig.  3  (6)  goes  out  and  the  temperature  display  stops  flashing

when the temperature is sufficiently cold again.
If the alarm status persists: (see Malfunction).

Note

Food may be spoilt if the temperature is not cold enough.

u

Check the quality of the food. Do not consume spoiled food.

5.2.1 Muting the temperature alarm

The  audible  alarm  can  be  muted.  When  the  temperature  is

sufficiently cold again, the alarm function is active again.

u

Press alarm button

 Fig. 3 (6).

w

The audible alarm is silenced.

5.3 Refrigerator compartment

The  natural  circulation  of  air  in  the  refrigerator  compartment

results  in  zones  differing  in  temperature.  It  is  coldest  directly

above the vegetable drawers and at the rear wall. It is warmest

at the top front of the compartment and in the door.

5.3.1 Food refrigeration

u

Store  perishable  food  such  as  ready-to-serve  dishes,  meat

products  and  sausages  in  the  coldest  zone.  Place  butter

and preserves in the upper area and in the door (see Appli-

ance at a glance).

u

Use  recyclable  plastic,  metal,  aluminium  and  glass

containers and cling film for wrapping.

u

Use the front area of the refrigerator compartment floor only

for  briefly  putting  down  cooled  products,  e.g.  when  rear-

ranging  and  sorting.  However  do  not  leave  cooled  products

there  otherwise  they  may  be  pushed  back  or  tipped  over

when the door is closed.

u

Do  not  store  food  too  close  together  to  enable  good  air

circulation.

u

To  safeguard  bottles  from  tipping  over:  move  the  bottle

holder.

5.3.2 Setting the temperature

The temperature depends on the following factors:

-

the door opening frequency

-

the  room  temperature  at  the  site  where  the  appliance  is

installed

-

the type, temperature and quantity of frozen food

Temperature setting to be recommended: 5 °C
The temperature can be changed continuously. Once the 1 °C

setting is reached, it starts again with 9 °C.

u

To access temperature adjustment: press the setting button

Fig. 3 (2) once.

w

The  LED  of  the  current  temperature  flashes  in  the  tempera-

ture display.

u

Press  the  setting  button

  Fig.  3  (2)  the  number  of  times

needed  until  the  required  temperature  shines  in  the  LED

display.
