12

Installing appliance in a row of kitchen units

To adapt the height of the appliance to the surrounding furniture

a top unit

➊

 can be added. A gap of at least 50 mm depth must

be provided behind and

along the entire width of

this unit so as to ensure

sufficient ventilation. The

area of ventilation under-

neath the ceiling should be

at least 300 cm

2

.

When setting up the

appliance next to a wall

➍

, a distance of approx.

50 mm must be provided

on the hinge side between

the appliance and the wall

(for the handle when the

door is open).

➊

 top unit

➋

 refrigerator-freezer

➌

 kitchen unit side panel

➍

 wall

Malfunctions

Your appliance is designed and manufactured for a lengthy, reli-

able operating life with no malfunctions. If a malfunction none-

theless occurs during operation, check whether it is due to an

operating error. Please note that even during the warranty period

the resultant servicing costs in this case will have to be borne by

the owner.

You may be able to rectify the following faults by checking

the possible causes yourself:
   Appliance does not function, display is unlit:

– Is the appliance switched on?

– Is the plug correctly fitted in the mains socket?

– Is the socket fuse intact?

   Loud running noise:

– Is the appliance set up firmly on the floor?

– Does the appliance cause nearby items of furniture or objects

to vibrate? Please note that noises caused by the refrigerant

circuit cannot be avoided.

   The temperature is not low enough:

– Is the temperature setting correct (see "Setting the tempera-

ture")?

– Have excessive amounts of fresh food been placed in the ap-

pliance?

–  Does the separately installed thermometer show the correct

reading?

–  Is the ventilation system working properly?

–  Is the appliance set up too close to a heat source?
If none of the above causes applies and you cannot eliminate

the fault yourself, please contact your nearest after-sales service

point. Please state the

appliance designation

!

,

service number

"

,

  appliance number

§

of the rating plate (see fig.) The type

plate is located in the refrigerator

compartment on the left-hand side.

Shutting your appliance down

If your appliance is to be shut down for any length of time, switch

it off and disconnect the plug or remove the fuse. Clean the ap-

pliance and leave the door open in order to prevent unpleasant

smells.

The refrigerant circuit has been tested for leaks.

The appliance complies with current safety regulations

and EC directives 2006/95/EC and 2004/10/EC.

Defrosting

Refrigerator compartment

The refrigerator compartment

defrosts automatically. The water

that forms on the rear wall drains

into a reservoir at the back of the

appliance and evaporates auto-

matically through the compressor

heat.

Ensure that the water can flow without hindrance through the

hole above the vegetable bins (see "Cleaning").

Freezer compartment

The No-frost system automatically defrosts the appliance.

Ani moisture arising collects on the evaporator and freezes, and

is periodically defrosted and evaporated.

Cleaning

•

  Before cleaning, always switch off the appliance. Discon-

nect from the mains or un-screw or switch off the fuse.

•

Wash shelves, glass plates and other options by hand.

•

  Clean the outer walls, inside and appliance by hand with lu-

kewarm water and a little detergent. Because of the risk of

injury and damage to the appliance, steam cleaning equipment

should not be used.

•

  Never use abrasive or scouring sponges. Do not use concentra-

ted cleaning agents and never use abrasive or acid cleaners or

chemical solvents.

•

  We recommend using a soft cloth and an all-purpose cleaner

with a neutral pH value. Only use food safe cleaning materials

inside the appliance.

•

For stainless-steel appliances*:

-    Clean the side panels and door surfaces with a clean and soft

cloth. If necessary, use a moist cloth (water + detergent). Alter-

natively, use a micro-fibre cloth.

•

  Ensure that no cleaning water penetrates into the electrical

components, drain gulley* or ventilation grilles. Wipe the app-

liance dry.

•

  Do not damage or remove the type plate on the inside of the

appliance. It is very important for servicing purposes.

•

  Clean the

drain hole

 on the rear wall above the vegetable bins

often Fig.

A

, arrow.

  If necessary, clean with a thin object, e.g. a cotton swab or

similar.

•

  Ensure that none of the wires or other components are dis-

lodged, bent or damaged.

•

  Then connect/switch on the appliance.

* according to model and design

Do not install the appliance side-by-side with another refrigerator

or freezer. This is important to prevent condensation and conse-

quential damage from it.
