10

Cooling

Storage example

➊

 butter, cheese

➋

 eggs

➌

 bottles, cans, tubes

➍

 frozen food, ice cubes

➎

 meat, sausage prod-

ucts, dairy products

➏

 baked goods, pre-

cooked meals, drinks

➐

 fruit, vegetables, salad,

Note

•  Food which gives off or

absorbs odours and fla-

vours as well as liquids

should always be stored

covered or in closed con-

tainers. High- percent-

age alcohols should be

tightly sealed and stored

upright.

•  Fruit, vegetables and

salad can be stored un-

packed in the bins.

•  Reuseable plastic, metal,

aluminium and glass

containers can be used for packaging.

Refrigerating with fan

This achieves a relatively even temperature distribu-

tion over at all storage levels; all foods are equally

cool, at an adjustable temperature. Due to the en-

forced air circulation, the various temperature ranges

of normal operation are raised.
It is generally recommended:

-  with high room temperature (above approx. 30 °C),

-  with high humidity, e.g. on summer days.
Cooling by circulating air uses slightly more energy. To save

energy, the fan automatically switches off when the door is

opened.

Switching on/off:

Switching on the fan:

-    press the fan button

2

(Fig. A1)

-    the button lights up*

-    the fan is switched on.

Switching off the fan

-    press the fan button

2

 (Fig. A1)

-    the fan button goes out*

-    the fan is switched off.

9

7

5

3

1

-15

-18

-21

-25

-32

°C

Changing shelf arrangement

Remover door racks

, Fig.

A2/A3

Lift the racks vertically upwards, remove

from the front and reinsert at another

height in the reverse order.
By

pushing the bottle holder

, Fig.

A2/A3

, you can secure bottles against

tipping over when opening and closing

the door.

The holder can be removed

for cleaning:

-    fig.

 A2: The holder slides and re-

leases left or right along the door stops.

-  fig. A3:

Pull out the retaining bracket,

then rotate the mount downwards and

remove it.

Fig.

A5.

 If you need space for large

bottles and containers, then simply push

half of glass shelf

1

 back. For cleaning

the holder

2

 can be used to remove

the half glass shelves.

1

2

Interior light

Light-bulb specifications:

 25 W (never use a bulb rated at

more than 25 W). The voltage should agree with the details on

the type plate. Socket: E 14.
Replacing the bulb:

Pull out the mains plug or remove/unscrew the fuse.

•  Push the sides 1 of the lamp cover together according to Fig.

F1

, unlatch and detach 2.

•  Replace the light bulb according to Fig.

F2

. When inserting

the new bulb, make sure the seal is correctly positioned in the

socket.

•  Attach the cover at the rear again and lock into place on sides.

Note

-  Place food inside the appliance as shown in the diagram. This

allows the appliance to save energy during operation.

-  Shelves, drawers and baskets are arranged for optimum en-

ergy efficiency on delivery.

The shelves, Fig.

A4

, can be adjusted

according to the height of frozen food; to

do this, lift the shelf fowards, pull out half

way and move down (or up).
Always insert trays with stop bar/raised

edge at the back upwards, otherwise

food may freeze onto the rear wall.

* according to model and design
