Liebherr CNesf 4003 Comfort NoFrost - Инструкция по эксплуатации - Страница 12

*

u

To  dismantle  the  shelves:  remove

the trims and side parts.*

u

To  dismantle  the  storage  rack:

remove  the  protective  film  from  the

decorative trims.*

*

u

Lift out the boxes and lift the covers

for removal.*

*

u

To empty the water collecting tray:

Remove  the  water  tank.  Carefully

disengage  the  tray  forwards  and

then lower for removal.*

*

After cleaning:

u

Wipe dry the appliance and items of equipment.

u

Connect the appliance and switch it on again.

u

Switch on SuperFrost (see 5.4.4) .

When the temperature is sufficiently cold:

u

Put the food back inside.

6.3 Cleaning the IceMaker*

Fig. 13

The IceMaker has to be switched on.

u

Pull out the drawer and remove the ice cubes.

u

Clean  the  drawer  with  warm  water  and  mild  washing-up

liquid.

u

When the drawer is pulled out, hold down the On/Off button

(about 10 seconds).

w

After  about  1  s  the  LED  goes  out,  the  IceMaker  is  switched

off.

w

After about 10 s the LED flashes for about 60 s.

u

Slide in the drawer while the LED is flashing.

w

The ice-cube tray of the IceMaker turns to a skew position.

u

Remove the drawer.

u

Clean  the  ice  cube  tray  with  warm  water.  If  necessary,  use

mild washing-up liquid. Then rinse.

Switch the IceMaker on again.

u

Press the ON/OFF button until the LED shines, then slide in

the drawer.

w

The IceMaker starts producing ice cubes.

If washing-up liquid was used:

u

throw away the first three loads of ice cubes to get rid of any

remaining washing-up liquid.

6.4 Changing the interior light with bulb

Bulb data

max. 25 W

Fitting: E14

Type of current and voltage must conform with the details on

the type plate

u

Switch off the appliance.

u

Pull out the power plug or

switch off the fuse.

u

Take  holder  of  the  cover

Fig.  14  (1)  at  the  front

and  unhook  it  at  the

back.

u

Change

the

bulb

Fig. 14 (2).

u

Put  the  cover

  Fig.  14  (1)

back in place.

Fig. 14

6.5 Customer service

First  check  whether  you  can  correct  the  fault  yourself  by  refer-

ence to the list (see Malfunction). If this is not the case, please

contact  the  customer  service  whose  address  is  given  in  the

enclosed customer service list.

WARNING

Risk of injury if repair work is not carried out professionally!

u

Have  any  repairs  and  action  -  not  expressly  specified  -  on

the  appliance  and  mains  cable  carried  out  by  service

personnel only. (see Maintenance)

u

Read  the  appliance

designation

Fig.  15  (1),  service

No.

  Fig.  15  (2)  and

serial  No.

  Fig.  15  (3)

off  the  type  plate

located  inside  the

appliance  on  the  left-

hand side.

Fig. 15

u

Notify  the  customer  service,  specifying  the  fault,  appliance

designation

 Fig. 15 (1), service No. Fig. 15 (2) and serial No.

Fig. 15 (3).

w

This will help us to provide you with a faster and more accu-

rate service.

u

Keep  the  appliance  closed  until  the  customer  service

arrives.

w

The food will stay cool longer.

u

Pull out the mains plug (not by pulling the connecting cable)

or switch off the fuse.

7 Malfunction

Your  appliance  is  designed  and  manufactured  for  a  long  life

span  and  reliable  operation.  If  a  malfunction  nonetheless

occurs  during  operation,  check  whether  it  is  due  to  a  handling

error.  In  this  case  you  will  have  to  be  charged  for  the  costs

incurred,  even  during  the  warranty  period.  You  may  be  able  to

rectify the following faults yourself:
Appliance does not work.

→

The appliance is not switched on.

Malfunction

12
