5.4.5 Drawers

Note

The  energy  consumption  increases  and  the  cooling  perform-

ance decreases if there is insufficient ventilation.

For appliances with NoFrost:

u

Leave the bottom drawer in the appliance!

u

Always keep the air slits of the fan free at the rear wall!

u

To store frozen food directly on the shelves: pull the drawer

forwards and lift it out.

5.4.6 Shelves

u

To  remove  the  shelf:  lift  up  at  the  front

and pull out.

u

To  put  the  shelf  back:  simply  push  in  as

far as it will go.

5.4.7 VarioSpace*

Apart  from  being  able  to  remove

the  drawers,  you  can  also

remove  the  shelves,  creating

space  for  large  items  of  frozen

food.  Poultry,  meat,  large  pieces

of  game  and  high  bakery  prod-

ucts  can  be  frozen  in  one  piece

and prepared.

u

The  maximum  load  of  frozen

food  for  the  drawers  is  25  kg

each  and  for  the  shelves

35 kg each.

5.4.8 Information system*

Fig. 11

(1) Ready-made meals, ice

cream

(4) Sausages, bread

(2) Pork, fish

(5) Game, mushrooms

(3) Fruit, vegetables

(6) Poultry, beef/veal

The  figures  indicate  the  storage  time  in  months  for  several

types  of  frozen  food  in  each  case.  Storage  times  given  are

guide times.

5.4.9 Cold storage accumulators*

The  cold  storage  accumulators  prevent  the  temperature  from

rising too fast in the event of power failure.

Using cold storage accumulators*

u

Place the cold storage accumula-

tors  in  the  top  freezer  compart-

ment to save space.

u

Place  the  frozen  cold  storage

accumulators  on  the  frozen  food

in  the  upper  front  area  of  the

freezer compartment.

5.4.10 IceMaker*

The  IceMaker  and  the  water  reservoir  situated  in  the  refriger-

ator  compartment  can  be  used  to  produce  ice  cubes  or  to

provide chilled drinking water.
The  IceMaker  is  in  the  top  drawer  of  the  freezer  compartment.

The drawer is marked "IceMaker".
Make certain that the following conditions are met:

-

The appliance is level.

-

The appliance is connected.

-

The freezer compartment is switched on.

-

The water tank was cleaned with water and is filled.

Filling the water tank*

WARNING

Risk of poisoning!

u

The water quality has to comply with the drinking water ordi-

nance of the respective country (e.g. 98/8

u

The  IceMaker  serves  exclusively  for  making  ice  cubes  in

household quantities and has to be operated with water suit-

able for the purpose.

NOTICE

Risk of damage to the IceMaker!

Liquids  containing  sugar,  such  as  soft  drinks,  fruit  juices  or

similar,  gum  up  the  pump  and  therefore  lead  to  total  pump

failure and, as a consequence, to damage to the IceMaker.

u

Fill  the  water  reservoir  with  drinking  water  only!  Do  not  use

any liquids containing sugar, such as soft drinks, fruit juices

or similar!

The  IceMaker  is  supplied  with  water  from  a  water  tank  in  the

refrigerator compartment (see Appliance at a glance).

Before initial operation:

u

clean  the  water  tank  thoroughly  with  water  to  remove  any

dust etc.

u

Pull the water tank forwards.

u

Open the front flap and fill the

tank with water.

u

Place  the  filled  water  tank  in

the  holder  and  slide  it  all  the

way back.

Control

10
