u

Press alarm button

 Fig. 3 (7).

w

The door alarm is silenced.

5.2 Temperature alarm

The audible alarm sounds if the freezer temperature is not cold

enough.
The alarm button flashes at the same time.
The cause of the temperature being too high may be:

-

warm fresh food was placed inside

-

too much warm ambient air flowed in when rearranging and

removing food

-

power failure for some time

-

the appliance is faulty

The  audible  alarm  is  automatically  silenced,  the  alarm  button

Fig.  3  (7)  goes  out  and  the  temperature  display  stops  flashing

when the temperature is sufficiently cold again.
If the alarm status persists: (see Malfunction).

Note

Food may be spoilt if the temperature is not cold enough.

u

Check the quality of the food. Do not consume spoiled food.

5.3 Refrigerator compartment

The  natural  circulation  of  air  in  the  refrigerator  compartment

results  in  zones  differing  in  temperature.  It  is  coldest  directly

above  the  plate  separating  off  the  BioFresh  zone  and  at  the

rear wall. It is warmest at the top front of the compartment and

in the door.

5.3.1 Food refrigeration

Note

The  energy  consumption  increases  and  the  cooling  perform-

ance decreases if the ventilation is inadequate.

u

Always keep the air slits of the fan free.

u

Place butter and preserves in the upper area and in the door

(see Appliance at a glance).

u

Use  recyclable  plastic,  metal,  aluminium  and  glass

containers and cling film for wrapping.

u

Use the front area of the refrigerator compartment floor only

for  briefly  putting  down  cooled  products,  e.g.  when  rear-

ranging  and  sorting.  However  do  not  leave  cooled  products

there  otherwise  they  may  be  pushed  back  or  tipped  over

when the door is closed.

u

Do  not  store  food  too  close  together  to  enable  good  air

circulation.

u

To  safeguard  bottles  from  tipping  over:  move  the  bottle

holder.

5.3.2 Setting the temperature

The temperature depends on the following factors:

-

the door opening frequency

-

the  room  temperature  at  the  site  where  the  appliance  is

installed

-

the type, temperature and quantity of frozen food

Temperature setting to be recommended: 5 °C
The temperature can be changed continuously. Once the 3 °C

setting is reached, it starts again with 9 °C.

u

To access temperature adjustment: press the setting button,

refrigerator compartment

 Fig. 3 (2) once.

w

The  LED  of  the  current  temperature  flashes  in  the  tempera-

ture display.

u

Press the setting button, refrigerator compartment

 Fig. 3 (2)

the  number  of  times  needed  until  the  required  temperature

shines in the LED display.

Note

u

Long  pressing  of  the  setting  button  sets  a  slightly  colder

value  within  a  small  temperature  range  (e.g.:  between  5  °C

and  6  °C).  The  LED  of  the  next  lower  temperature  range

then shines in the temperature display.

5.3.3 Relocating the shelves

The  shelves  have  stops  preventing  them  from  being  uninten-

tionally pulled out.

u

Lift the shelf and draw it out forwards.

u

Insert  shelf  with  the  raised  edge  pointing  upwards  at  the

back.

w

The food does not freeze onto the rear wall.

5.3.4 Using the sectioned shelf

Fig. 10

u

The glass shelf with stop face (2) has to be at the back.

5.3.5 Moving the storage rack

u

Remove  storage  rack  according  to

illustration.

5.3.6 Removing the bottle holder

u

Remove  the  bottle  holder  according

to the illustration.

5.4 BioFresh compartment

The BioFresh compartment allows some types of fresh food to

be stored up to three times longer than in conventional refriger-

ators, without compromising quality.
For  food  with  an  indicated  best  before  date,  the  date  specified

on the packaging always applies.

5.4.1 HydroSafe

The  HydroSafe  at  the  moist  setting  is  suited  for  storing

unwrapped salad, vegetables and fruit with high inherent mois-

ture.  When  the  drawer  is  well  filled,  a  dewy  climate  with  up  to

Control

8
