u

Press  the  setting  button,  freezer  compartment

  Fig.  3 (5)  the

number  of  times  needed  until  the  LED  pattern  of  the  value

wanted shines.

u

To confirm: Press the SuperFrost button

 Fig. 3 (6).

w

The  temperature  is  indicated  again  in  the  temperature

display.

u

To deactivate the setting mode: press On/Off button, freezer

compartment

 Fig. 3 (8).

-or-

u

Wait for 5 minutes.

5.4.6 Setting the humidity in the HydroSafe

u

  Low  humidity:  move  the  regulator  to

the left.

u

  High  humidity:  move  the  regu-

lator to the right.

5.4.7 Drawers

Fig. 12

u

Pull out the drawer, lift it at the back and draw it forwards for

removal.

u

Push the rails in again!

Fig. 13

u

Pull out the rails.

u

Attach  the  drawer  to  the  rails  and  push  it  in  until  it  engages

audibly at the back.

5.4.8 Humidity control plate

Fig. 14

u

To  remove  the  humidity  control  plate:  Having  removed  the

drawers,  carefully  draw  the  plate  forwards  and  lower  it  for

removal.

u

To  insert  the  humidity  control  plate:  Insert  the  cover  mould-

ings  of  the  plate  into  the  rear  holder

  Fig.  14  (1)  from  under-

neath and engage them in the holder

 Fig. 14 (2) at the front.

5.5 Freezer compartment

You  can  store  frozen  food,  make  ice  cubes  and  freeze  fresh

food in the freezer compartment.

5.5.1 Freezing food

The  rating  plate  indicates  the  maximum  quantity  of  fresh  food

you  can  freeze  within  24  hours  (see  Appliance  at  a  glance)

under "Freezing capacity ... kg/24h".
The maximum load of frozen food for the drawers is 25 kg each

and for the shelves 35 kg each.

CAUTION

Risk of injury due to broken glass!

Bottles  and  cans  containing  drinks  may  burst  when  being

frozen. This applies particularly to sparkling drinks.

u

Do not freeze bottles and cans containing drinks!

In  order  that  the  food  is  rapidly  frozen  through  to  the  core,  do

not exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg

- Meat up to 2.5 kg

u

Pack  the  food  in  portions  in  freezer  bags,  reusable  plastic,

metal or aluminium containers.

5.5.2 Thawing food

- in the refrigerator compartment

- at room temperature

- in a microwave oven

- in a conventional or fan oven

u

Food  once  thawed  should  be  re-frozen  only  in  exceptional

cases.

5.5.3 Setting the temperature

Temperature setting to be recommended: -18 °C
The  temperature  can  be  changed  continuously.  Once  the

-32 °C setting is reached, it starts again with -15 °C.

u

To  access  temperature  adjustment:  press  setting  button,

freezer compartment

 Fig. 3 (5) once.

w

The  LED  of  the  current  temperature  flashes  in  the  tempera-

ture display of the freezer compartment.

u

Press  the  setting  button,  freezer  compartment

  Fig.  3 (5)  the

number  of  times  needed  until  the  required  temperature

shines in the LED display.

Note

u

Long  pressing  of  the  setting  button  sets  a  slightly  colder

value  within  a  small  temperature  range  (e.g.:  between

-15  °C  and  -18  °C).  The  LED  of  the  next  lower  temperature

range then shines in the temperature display.

5.5.4 SuperFrost

With  this  function  you  can  freeze  fresh  food  quickly  through  to

the  core.  The  appliance  operates  with  maximum  refrigeration.

The noise of the refrigeration unit may be temporarily louder as

a result.
The  maximum  amount  of  fresh  food  which  can  be  frozen  in  24

h  is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".  This  amount  varies  according  to  the  model  and  climate

rating.
You do not have to activate SuperFrost in the following cases:

-

when placing frozen food in the freezer

-

when freezing up to about 2 kg fresh food daily

Freezing with SuperFrost

u

Briefly press the SuperFrost button

 Fig. 3 (6).

w

The SuperFrost button shines.

w

The  freezer  temperature  drops,  the  appliance  operates  with

the maximum refrigerating capacity.

In case of a small amount of food to be frozen:

u

wait about 6 h.

u

Place the fresh food in the top drawers.

In  case  of  the  maximum  amount  of  food  to  be  frozen  (see

type plate):

u

wait about 24 h.

u

Place food in the drawers.

w

SuperFrost is automatically deactivated after about 65 h.

w

The SuperFrost button is dark.

Control

10
