63

FRIDGE

UNIT

9

3

3.6

CRISPER

10

11

12

11

Display

13

Crisper

12

Up/Down

www.fhiaba.com ∙ www.thevettagroup.com

Englis

h

Français

Before starting

Shows the temperature of the Crisper-Fresco compartment.

Allows  switching  on  and  off  of  only  the  Crisper-Fresco  compartment
(press
for three seconds).

Using the Up and Down buttons, it is possible to change the
temperature set for the Crisper-Fresco compartment.

Crisper-Fresco control panel

8

3

3.5

3.4

1

Unit

2

Fridge

3

Menu

4

Up/down

Fridge

5

Display

6

Up/Down

Freezer

(TriMode)

7

Enter

8

Ice maker

9

Alarm

www.fhiaba.com ∙ www.thevettagroup.com

Before starting

The innovative electronic control system designed by Fhiaba maintains constant temperature in multiple compartments and
displays it on the control panel. It also allows user interaction making it possible to personalize settings of various functions and
to alert the user with sound and/or visual messages should any malfunction occur in the appliance.

Electronic Control

Switches the appliance (all compartments) between ON and STAND BY
(press for three seconds).

Allows switching on and off of only the refrigerator compartment
(press for three seconds).

Allows access to the appliance function menu

It shows the temperature of the refrigerator and freezer compartments,
the date and time, Menu functions and visual messages.

By selecting Up/Down the preset temperature can be changed accord-
ing to the selected function mode (freezer, refrigerator, Crisper-Fresco).

Confirms  activation  or  deactivation  of  the  selections  made  in  the
Menu.

Allows activating or deactivating the automatic ice production.

Blinks to signal user alerts such as door left open, also in combination with
a sound signal which can be deactivated by pressing the button.

Using the Up and Down buttons, it is possible to change the set tempera-
ture of the refrigerator and navigate through the interactive menu.

Main control panel

1

2

3

4

5

6

7

9

8

ICE MAKER

ENTER

FRIDGE

UNIT

www.fhiaba.com ·  info@fhiaba.com ·  Tel +39 (0)434 420160 ·  Fax +39 (0)434 420161

Installation Guide

EN

Post installation control

 Check that the front levelling feet have been properly

installed.

 Check that the connection to the water system does

not have any leaks and that the closing tap is easily ac-
cessible.

 Check that the electrical connection is correctly in-

stalled and that the multipole switch and socket are easily
accessible.

 Check the per fect alignment of the appliance with

adjacent structures.

 Check that all adhesive tape and external or internal

temporary protective devices have been removed.

 Check the per fect closing of the doors and the smooth

sliding of the drawers and shelves.

Start up

  To start the appliance, connect the plug to the electrical

mains: at this point, when opening the door, the control

panel will usually visualize the message “Stand by”, and all

the panel keys be off

  To turn on all the appliance compartments, press the Unit

 button for three seconds. The display will show the mes-

sage “Initial test” for approx. 2 minutes. After this phase the

compressors will start up and remain on until the default
temperature set up in the factory is reached. Do bear in
mind that this condition could last several hours. If the ap-
pliance is provided with an Ice Maker, prior to switching it

on make sure that the water filter cartridge is installed, then
fill the water system. To this purpose switch off the Ice Mak

-

erand per forme a manual clean procedure. At the end
switch the Ice Maker on again by touching the   button.

  For further information about the appliance operation,

refer to the User Manual.

Ventilation is insured by a forced air system through a grille
located in the upper part of the appliance.
This grille should never be covered by panels or any other

devices that could reduce its efficiency.

Please refer to page 5-6 to ensure correct air circulation.

StandPlus and X-Pro Series

If  at  the  first  start  -  up  the  message  Stand  by  does  not  ap

-

pear, but other messages appear, such as Fridge too warm,

Fresco too warm, Freezer too warm, or sound signals are ac-

tivated, it means that the appliance has already started the

cooling process. If this is the case, deactivate any possible

acoustic signals by pressing the Alarm button, close the door

and wait until the set temperature is reached.

It is necessary to let the unit reach the correct temperature

before foods are stored inside.
