WORX 40 В, АКБ 4 А*ч х2, ЗУ 2А х2 WG749E - Инструкция по эксплуатации - Страница 13

13

Cordless Lawn mower

               EN

2. Motor stops

while mowing.

A. Release Operating Bail to turn

mower off. Remove safety key and

batteries,turn mower over and check

that blade is free to turn. If not free,

return to an authorized servicer.

Blade should turn freely.

B. Raise cutting height of wheels to

highest position and start mower.

C. Has battery been fully charged?

Plug in charger and wait for green

light to come on.

D. Avoid overloading the mower. Slow

down the cutting pace by pushing

mower slower or raise the cut height.

Or both.

3. Mower runs

but cutting

performance is

unsatisfactory,

or does not cut

entire lawn.

A. Has battery been fully charged? Plug

in charger and wait for green light to

come on.”

B. Release Operating Bail to turn mower

off. Remove safety key and batteries.

Turn mower over and check: Blade for

sharpness - Keep blade sharp. Deck and

discharge chute for clogging.

C. Wheel height adjustment may be set

too low for grass condition. Raise cutting

height.

4. Mower is too

hard to push.

A. Raise cutting height to reduce

deck drag on grass. Check each

wheel for free rotation.

5. Mower is

abnormally

noisy and

vibrates.

A. Release Operating Bail to turn

mower off. Remove safety key

and batteries. Turn mower on

side and check blade to ensure it

has not been bent or damaged. If

blade is damaged, replace with a

replacement blade. If the underside

of the deck is damaged return mower

to an Authorized service center.

B. If there is no visible damage to the

blade and the mower still vibrates:

Release Operating Bail to turn mower

off, Remove safety key and batteries,

and remove blade. Rotate blade 180

degrees and retighten. If mower

still vibrates, return the mower to an

authorized service center.

6. Battery

charger LED’s

not on.

A. Check plug connection.

B. Replace charger.

7. Battery

charger LED

does not flip to

green.

A. Battery needs to be diagnosed.

Take to authorized service center.

8. Mower not

picking up

clippings with

the Grass

Collection Bag.

A. Remove mulch plate when

bagging.

B. Chute clogged. Release Operating

Bail to turn mower off. Remove safety

key and batteries. Clear chute of

grass clippings.

C. Too much cut grass. Raise cutting

height of wheels to shorten length

of the cut.

D. Bag full. Empty bag more often.

9. When

mulching there

are clippings

visible.

A. Too much cut grass. Raise cutting

height of wheels to shorten length of

the cut. Do not cut off more than 1/3

of total length.

B. Check blade for sharpness. Always

keep blade sharp.

10. Low or

diminished run-

time after many

uses

A. Return to Authorized Service

location - may need new battery.

11. The battery

charger LED

flashes red and

the battery can’t

be charged.

A. The battery overheats after

continuous use. Remove battery

from the charger and allow it to cool

to 42°C or less.

ENVIRONMENTAL

PROTECTION

Disposal

The machine, its accessories and packaging

materials should be sorted for environmentally friendly

recycling. The plastic components are labeled for

categorized recycling.
