11

WARNING:

 Petrol is highly flammable.

Store fuel in containers specifically designed for this
purpose.
Refuel outdoors only, before starting the engine and do
not smoke while refueling or handling fuel.
Never remove the cap of the fuel tank or add petrol while
the engine is running or when the engine is hot.
If petrol is spilled, do not attempt to start the engine but
move the machine away from the area of spillage and
avoid creating any source of ignition until petrol vapors
have dissipated.
Replace all fuel tanks and container caps securely.
Before tipping the lawn mower to maintain the blade or
drain oil, remove fuel from tank.

WARNING:

 Never fill fuel tank indoors, with

engine running or until the engine has been allowed to
cool for at least 15 minutes after running.

7-2 TO START ENGINE AND ENGAGE

BLADE

1. The unit is equipped with a rubber boot over the end of

the spark plug, make certain the metal loop on the end
of the spark plug wire (inside the rubber boot) is
fastened securely over the metal tip on the spark plug.

2. When starting cool or warm engine, turn throttle choke

lever at anywhere between “

” position and “

”

position. When operating, turn throttle choke lever to
“

” position.

(Fig. 19)

3. Standing behind the unit, grasp the stop control

handle and hold it against the upper handle as shown
in

Fig. 20

.

4. Grasp the starter handle as shown

Fig. 20

 and pull it

up rapidly. Return it slowly to the rope guide bolt after
engine starts. Release the stop control handle to stop
the engine and blade.

Start the engine carefully according to
instructions and with feet well away from the
blade.

Do not tilt the lawn mower when starting the
engine. Start the mower on a level surface, free
of high grass or obstacles.

Keep hands and feet away from the rotating
parts. Do not start the engine when standing in
front of the discharge opening.

7-3 OPERATION PROCEDURES

During operation, tightly hold the stop control handle with
both hands.

Note:

During operation, when the stop control

handle is released, the engine will stop and thus stopping
the lawn mower from operating.

WARNING!

 In order to avoid any unintentional

start-ups of the lawn mower, it comes equipped with an
engine brake which must be pulled back before the
engine can be started. When the engine control lever is
released it must return to its initial position, at which point
the engine automatically switches off.

Note:

Engine brake (brake handle): Use the lever

to stop the engine. When you release the lever the engine
and the blade stop automatically. To mow, hold the lever in
the working position. Before you start to mow, check the
start/stop lever several times to be sure that it is working
properly. Ensure that the tension cable can be smoothly
operated (i.e. is not catching or kinking in any way).

7-4 TO STOP ENGINE

CAUTION:

The blade continues to rotate for a

few seconds after the engine is shut off.
1. Release the stop control handle to stop the engine

and blade.

2. Disconnect and ground the spark plug wire as

instructed in the separate engine manual to prevent
accidental starting while equipment is unattended.

7-5 CONNECTION FOR AUTO MOVE

For PLM4621N2

Grip the self-drive control handle, the lawn mower will
move forward automatically with about 3.6 km/h, release
the self-drive handle, the lawn mower will stop move.

For PLM4622N2

The mower is equipped with a speed adjusting system
which can adjust 3 speeds from 3.0 km/h to 4.5 km/h.
The step as below:
1. Release the self-drive control handle until the lawn

mower doesn’t go forward.

2. Adjust the appropriate speed which you want.
3. Grasp the self-drive control handle to go on mowing.

(Fig. 21)

CAUTION:

Your mower is designed to cut normal

residential grass of a height no more than 250 mm.
Do not attempt to mow through unusually tall dry or wet
grass (e.g., pasture) or piles of dry leaves. Debris may
build up on the mower deck or contact the engine exhaust
presenting a potential fire hazard.

7-6 FOR THE BEST RESULTS WHEN

MULCHING

Clear lawn of debris. Be sure that the lawn is clear of
stones, sticks, wire or other foreign objects which could be
accidentally thrown out by the mower in any direction and
cause serious personal injury to the operator and others
as well as damage to property and surrounding objects.
Do not cut wet grass. For effective mulching do not cut
wet grass because it tends to stick to the underside of the
deck preventing proper mulching of the grass clippings.
Cut no more than 1/3 the length of the grass.
