5. ASSEMBLY

5-1 ASSEMBLING THE FOLDING

HANDLE

A) Fix the lower handlebars into the unit body with

locking knobs as shown.

(Fig. 3, Fig. 4, Fig. 5, Fig. 6)

B) Release the upper handlebars for folding. Connect the

upper handle and the lower handle with the locking
knob.

(Fig. 7, Fig. 8)

C) Position all cables over the handle shafts. Clamp them

around the middle of lower handles by the cable
clamps so that the cables are fixed on the outside of
the machine. Otherwise the cables may be pinched by
opening/closing the rear cover or forced by folding the
upper handle.

(Fig. 9)

5-2 MOUNTING AND DISMOUNTING THE

GRASS CATCHER

1. To fit: Lift the rear cover and hang the grass catcher on

the shaft of rear of mower.

(Fig. 10, Fig. 11)

2. To remove: Grasp and lift the rear cover, remove grass

catcher.

5-3 STARTER HANDLE

Move the starter handle from the engine to the rope guide.

(Fig. 12, Fig. 13)

5-4 HEIGHT OF CUT

Apply outward pressure to disengage lever from rack.
Move lever forward or back to adjust height.

(Fig. 14 and

see clause 7-9)

5-5 ADJUSTMENT FOR AN

APPROPRIATE HEIGHT

1) Back out the locking knob which fixed the lower

handle, refer to

Fig. 15

.

2) Refer to

Fig. 16

, move the lower handle up and down,

adjust it to the proper height.
There is 3 adjusting height to be choose on this type
lawn mower; at 1 height, lower handle to the ground is
highest., 3 height is the lowest.

3) Adjusting to the proper height, then fix the lower

handle by the locking knobs.

WARNING:

 The left side and right side of lower

handle must adjust to the same height.

6. “2 IN 1”

These lawn mowers can be retrofitted from its normal
function, based on the application purpose:
From lawn mower with rear collection to mulching mower.
What is mulching?
When mulching, the grass is cut in one working step, then
finely chopped and returned to the grass strip as natural
fertilizer.
Hints for mulch-mowing:
- Regular cut-back by max. 2 cm from 6 cm to 4 cm

grass height.

- Use a sharp cutting knife.
- Do not mow wet grass.
- Set max. engine speed.
- Only move at working pace.
- Regularly clean mulching wedge, housing inner side

and mowing blade.

ONE: Retrofitting for mulching mower

WARNING:

 Only with a stopped engine and

standstill cutter.

1. Raise the rear cover and remove the grass catcher.
2. Push the mulching wedge into the deck. Lock the

mulching wedge with the button into the opening on
the deck.

(Fig. 17, Fig. 18)

3. Lower the rear cover again.

TWO: Mowing with the grass catcher

WARNING:

 Only with a stopped engine and

standstill cutter.
1. For mowing with the grass catcher, remove the

mulching wedge and mount the grass catcher.

2. Removing the mulching wedge.
- Lift rear cover and remove the mulching wedge.

7. OPERATING INSTRUCTIONS

7-1 BEFORE STARTING

Service the engine with gasoline and oil as instructed in
the separate engine manual packed in your mower. Read
instructions carefully.

Guaranteed sound pressure level at
operator’s position (According to EN
ISO 5395-1 Annex F & EN ISO 5395-2,
EN ISO 4871)

85.1 dB(A) (K=3 dB(A))

84.3 dB(A) (K=3 dB (A))

Measured sound power level

93.7 dB(A) K=2.59 dB(A)

94.0 dB(A) K=1.80 dB(A)

Guaranteed sound power level
(According to 2000/14/EC)

  96 dB(A)

96 dB(A)

Vibration
(According to EN ISO 5395-1 Annex G
& EN ISO 5395-2)

7.38 m/s

2

K=1.5 m/s

2

5.18 m/s

2

K=1.5 m/s

2

Model

PLM4621N2

PLM4622N2
