The boundary cable is routed too imprecisely
so that edge areas of the grass surface can-
not be mowed (02/d).

■

The boundary cable is not routed lying direct-
ly next to itself when guided towards and
back from the edge to an obstacle inside the
lawn (02/e).

■

The entry points are set too far away from the
charging station (02/f).

■

The boundary cable is routed beyond the
edge of the grass surface (02/g).

■

When routing the boundary cable, the mini-
mum distance for corridors of 30 cm is under-
cut (02/h).

■

The boundary cable is routed too close (i.e.
at a distance of less than 20 cm) to obstacles
that cannot be driven over (02/i).

4.6

Connecting the charging station to the
power supply (04)

1. Place the power supply (04/4) in a dry loca-

tion that is protected against direct sunlight
and sufficiently close to the charging station
(04/1).

2. Connect the low voltage cable of the power

supply (04/5) and the cable of the charging
station (04/6) with each other.

3. Plug the power plug of the power supply

(04/2) into a power socket (04/3).

NOTE

We recommend connecting the power
supply to the mains supply via an earth
leakage circuit breaker (ELCB) with a
rated leakage current < 30 mA.

4.7

Checking the connections on the
charging station (04)

1. Check that both LEDs on the front side of the

charging station (09/1) light. If not:
■

Disconnect the mains plug.

■

Check that all plug connectors of the
power source and the boundary cable
are positioned correctly and check for
damage.

Status indications of the LEDs

LEDs

Operating states

Green

■

Lights up when the boundary
cable is laid correctly and the
loop is intact.

■

Flashes if a loop of the bound-
ary cable is not in order.

LEDs

Operating states

Yellow

■

Lights up if the power source is
intact.
