GB

4.5.1

Connecting the boundary cable to the
charging station (03/b)

1. Pull the boundary cable (03/4) out of the

packaging.

2. Remove the cover of the cable shaft (03/3)

on the connection (03/A).

3. Insulate the end of the boundary cable (03/6)

and insert into the terminal (03/7).

4. Close the terminal.

5. Lead the boundary cable through the strain

relief (03/5) out of the cable shaft with cable
reserve.

NOTE

The cable reserve allows smaller correc-
tions to be carried out on the cable guide
later.

6. Place the cover on the cable shaft.

4.5.2

Routing the boundary cable (01)

The boundary cable can be laid on the lawn and
as much as 10 cm under the turf. Laying under
the turf can be carried out by the dealer.

Both variants can be combined with one another.

IMPORTANT!
Danger of damaging the
boundary cable

If the boundary cable is
damaged or cut, the trans-
mission of the control sig-
nals to the appliance is no
longer possible. In this
case, the boundary cable
must be repaired or re-
placed. The boundary ca-
bles are available from
Kärcher.
■ Always route the bound-

ary cable directly on the
ground. If necessary,
secure with an addition-
al lawn peg.

■ When laying the bound-

ary cable and during op-
eration, protect the
boundary cable from
damage.

■ Do not dig or scarify in

the vicinity of the bound-
ary cable.

1. Attach the boundary cable at regular intervals

with lawn pegs or route it underground (at a
max. depth of 10 cm).

2. Route the boundary cable around obstacles:

see

chapter 4.5.3 "Excluding obstacles",

page 50

.

3. Create corridors between individual mowing

areas: see

chapter 4.5.4 "Enclosing corridors

(01/h)", page 50

.

4. Exclude excessive upward or downward

slopes: see

chapter 4.5.5 "Excluding down-

ward slopes", page 50

.
