LED lights

Battery status

All LEDs are lit

Fully charged (75-100%)

LED 1, LED 2, LED 3 are

lit

The battery is 50%-75%

charged

LED 1, LED 2 are lit

The battery is 25%-50%

charged

LED 1 is lit

The battery is 0%-25%

charged.

LED 1 flashes

The battery is empty.

Charge the battery.

To charge the battery

Charge the battery before the first use. The battery is

only 30% charged when supplied to the customer.

Note: The battery charger must be connected to the

voltage and frequency specified on the rating plate.

The battery does not charge if the battery temperature is

above 50°C. The battery charger decreases the

temperature of the battery before it starts to charge.
1. Connect one end of the power cord for the battery

charger into the socket of the battery charger.

2. Connect the other end of the power cord for the

battery charger in an grounded mains socket. The

LED on the battery charger flashes green one time.

(Fig. 30 )

3. Put the battery in the battery charger. The green light

on the charger comes on when the battery is

correctly connected to the battery charger.(Fig. 31 )

4. When all LEDs on the battery have come on the

battery is fully charged. Charge the battery for

maximum 24 hours.

5. To disconnect the battery charger from the mains

socket, pull the plug, not the power cord.

6. Remove the battery from the battery charger.

Battery charging status

A Husqvarna Li-ion battery can be charged or used at all

charging levels. The battery is not damaged. A fully

charged battery will not decrease its charge when the

battery is left in the charger.

LED display

Charging status

LED 1 flashes

0%-25%

LED 1 is lit, LED 2 flashes 25%-50%

LED 1, LED 2 are lit, LED

3 flashes

50%-75%

LED 1, LED 2, LED 3 are

lit, LED 4 flashes

75%-100%

LED display

Charging status

LED 1, LED 2, LED 3,

LED 4 are lit

Fully charged

To start the product

1. Put a charged battery in battery compartment

number 1 below the battery lid. For longer operation

time, put a second charged battery in battery

compartment number 2.

2. Turn the safety key to 1.(Fig. 32 )
3. Stay behind the product.
4. Press the ON/OFF button (A) on the control panel

and the green LED (B) comes on.(Fig. 33 ) When

you press the ON button, the two bars of the battery

indicator come on and show the levels of the two

batteries. After 2-3 seconds the battery indicator for

the battery not in operation goes off. The bar of the

battery in operation is shown for a longer time . (Fig.

34 )

5. Loosen the start inhibitor.(Fig. 35 )
6. Push the motor brake handle in the direction of the

handlebar.(Fig. 36 )

To use the drive on the wheels (LC

347VLi)

• Pull the drive bail in the direction of the handlebar to

start the drive.(Fig. 37 )

• Press + and - on the control panel to set the drive

speed in 4 steps.(Fig. 38 )

• Release the drive bail to disengage the drive, for

example when you go near an obstacle.

To use the SavE function

The product has a battery saving function (SavE) that

gives longer operation time.
1. Press the SavE button (A) to start the function. The

green LED comes on.(Fig. 39 )

2. Press the SavE button again to stop the function.

The green LED (B) goes out.

The SavE function stops automatically if the ground

conditions make it necessary to have a higher output.

The SavE function starts automatically when the ground

conditions let it.

High load function

When the product cuts long or wet grass, the motor

automatically increases rpm. The motor goes back to

standard mode when high load is not necessary.

To stop the product

The product stops automatically if you do not operate it

for 10 minutes. Always turn the safety key to 0 before

you let the product out of view.
