17

English (Original Instructions)

Function button

This lawn mower is equipped with a function button on

the rear end of the power head. This button is a manual

overdrive button that changes the RPM.
Press this button, the indicating light will be on and the

mower will be in the high-speed.You can mow more

efficiently when the grass is very thick.

Press this button again,the indicating light will be off and

then your mower will be in the auto mode. You can mow

slowly and this mode helps to save the energy and makes

your mower run for a longer time.

MOWING TIPS

■

Make sure the lawn is clear of stones, sticks, wires,

and other objects that could damage the lawn mower

blades or motor. Do not mow over property stakes or

other metal posts. Such objects could be accidentally

thrown by the mower in any direction and cause

serious personal injury to the operator and others.

■

For a healthy lawn, always cut off one-third or less of

the total length of the grass.

■

Do not cut wet grass, it will stick to the underside of

the deck and prevent proper bagging or mulching of

grass clippings.

■

New or thick grass may require a narrower cut or a

higher cutting height.

■

Clean the underside of the mower deck after each use

to remove grass clippings, leaves, dirt, and any other

accumulated debris.

■

When cutting long grass, reduce walking speed to

allow for more effective cutting and a proper discharge

of the clippings.

NOTE:

Always stop mower, allow blades to completely

stop, and remove the isolator key before cleaning

underneath the mower.

SLOPE OPERATION

 WARNING

Slopes are a major factor related to slip and fall

accidents that can result in severe injury. Operation on

slopes requires extra caution. If you feel uneasy on a

slope, do not mow it. For your safety, do not attempt to

mow slopes greater than 15 degrees.

■

Mow across the face of slopes, never up and down. Exercise

extreme caution when changing direction on slopes.

■

Watch for holes, ruts, rocks, hidden objects, or bumps

which can cause you to slip or trip. Tall grass can hide

obstacles. Remove all objects such as rocks, tree limbs,

etc., which could be tripped over or thrown by the blade.

 WARNING

Always inspect mower for missing or damaged parts

and blade for damage, uneven, or excessive wear prior

to use. Using a product with damaged or missing parts

could result in serious personal injury.

■

Do not tilt the lawn mower when starting the engine

or switching on the motor, unless the lawn mower has

to be tilted for starting. In this case, do not tilt it more

than absolutely necessary and lift only the part which

is away from the operator.

■

Do not start the engine when standing in front of the

discharge chute.

■

Do not put hands or feet near or under rotating parts.

Always keep clear of the discharge opening.

For complete charging instructions, refer to the operator’s

manual for the battery packs and chargers listed in the

specifi cations section.

TO INSTALL BATTERY PACK

See figure 8.

■

Lift and hold up the battery door.

■

Align the battery with the mower’s battery port.

■

Make sure the battery release button snaps in place

and that battery is fully seated and secure in the

mower before beginning operation.

■

If the machine is not going to be used immediately, do

not insert the switch key.

■

Close the door.

TO REMOVE BATTERY PACK

See figure 8.

■

Release the power lever to stop the product.

■

Remove the switch key.

■

Open the battery door.

■

Press the battery release button on the mower. This

will cause the battery to raise out of the tool slightly.

■

Remove battery pack from the product.

STARTING/STOPPING THE MOWER

See figure 9.

■

Put the switch key into the slot and press and hold the key.

■

Pull the power lever upward to the handle to start the

mower and release the key.

■

To stop the mower, release the power lever.

NOTE:

 A high-pitched noise and sparking may occur as

the electric motor decelerates. This is normal.
