16

English (Original Instructions)

INSTALLING SIDE DISCHARGE DEFLECTOR

See figure 6.

NOTE:

When using the side discharge deflector, do not install

the grassbox. The mulching plug should remain installed.

■

Lift the side discharge door.

■

Align the hooks on the defl ector with the hinge rod on

the underside of the door.

■

Lower the defl ector until the hooks are secured on the

mulch door hinge rod.

■

Release the defl ector and side discharge door.

SETTING BLADE HEIGHT

See figure 7.

When shipped, the wheels on the mower are set to a low-

cutting position. Before using the mower for the first time,

adjust the cutting position to the height best suited for your

lawn. The average lawn should be between 38 mm and 51

mm during cool months and between 51 mm and 70 mm

during hot months.

To adjust the blade height

■

To raise the blade height, grasp the height adjustment

lever and move it toward the back of the mower.

■

To lower the blade height, grasp the height adjustment

lever and move it toward the front of the mower.

OPERATION

 WARNING

Do not allow familiarity with products to make you

careless. Remember that a careless fraction of a

second is suffi cient to infl ict serious injury.

 WARNING

Always wear eye protection. Failure to do so could

result in objects being thrown into your eyes resulting

in possible serious injury.

 WARNING

Do not use any attachments or accessories not

recommended by the manufacturer of this product. The

use of attachments or accessories not recommended

can result in serious personal injury.

 WARNING

To prevent accidental starting that could cause serious

personal injury, always remove the battery pack from

the product when assembling parts.

 WARNING

Never operate the mower without the proper safety

devices in place and working. Never operate the mower

with damaged safety devices. Operation of this product

with damaged or missing parts could result in serious

personal injury.

UNFOLDING AND ADJUSTING LOWER HANDLE

See figure 2.

■

Pull and rotate the handle knobs 90° on both sides to

loosen the lower handles on both sides.

■

Move the lower handles to the operating position. You

may raise or lower the handle to a position comfortable

for you. There are 3 positions for you to choose. Release

the handle knobs to lock the lower handle into position.

NOTE:

 Ensure both sides are set at the same position for

proper assembly.

INSTALLING THE UPPER HANDLE

See figure 3.

■

Align the mounting holes on the upper handle and the

lower handle. Insert the carriage bolts and use the knobs

to tighten them. Repeat the operation on the other side.

INSTALLING THE GRASSBOX

See figure 4.

■

Lift the rear discharge door.

■

Lift the grass catcher by its handle and place under

the rear discharge door so that the hooks on the grass

catcher are seated on the door rod.

■

Release the rear discharge door. When installed

correctly, the hooks on the grass catcher will extend

through the openings on the rear discharge door.

INSTALLING THE MULCHING PLUG

See figure 5.

■

Lift and hold up the rear discharge door.

■

Grasp the mulching plug by its handle and insert it at a

slight angle, as shown.

■

Push the mulching plug securely into place.

■

Lower the rear discharge door.
