12
suitable for your device and follow the instructions in the operating
manual. The petrol lawn mower is intended only for amateur use.
WARNING! Do not use the device contrary to its intended use.
DESCRIPTION OF GRAPHIC PAGES
The numbering below refers to the components of the device
shown on the graphic pages of this manual.
1.
Wheel drive clutch lever
2.
Top handle
3.
Engine brake lever
4.
Shelf for drinks
5.
Handle fixing nut
6.
Rear discharge cover
7.
Bottom handle
8.
The fuel filler cap
9.
Air filter housing
10.
Manual fuel pump
11.
Side discharge cover
12.
The oil filler cap
13.
Driving wheel
14.
Cutting height adjustment lever
15.
Grass catcher
16.
Boot rope
17.
Rear discharge shutter
18.
Oil level indicator
19.
Oil drain plug
20.
Cutting knife
21.
Cutting knife mounting bolt
22.
Air filter cover
23.
Air filter
24.
Spark plug wire
25.
Spark plug
26.
Spark plug wrench
27.
Spark plug contacts
* There may be differences between the drawing and the product.
EQUIPMENT AND ACCESSORIES
1.
Grass catcher
- 1 pc.
2.
Bottom handle
- 1 pc.
3.
Top handle
- 1 pc.
4.
Shelf brackets drinks +
- 1 set.
5.
Rear discharge shutter
- 1 pc.
6.
Side discharge element
- 1 pc.
7.
Starting rope holder
- 1 pc.
8.
Clips
- 2 pcs.
9.
Bolts, nuts, screws
- 1 set.
PREPARATION TO WORK
WARNING! Do not operate the petrol mower without the grass
catcher with the rear discharge cover raised.
WARNING! All maintenance, repairs, adjustments and work
preparation activities must be performed with the engine off.
HANDLE ASSEMBLY
•
Install the lower handle (
7)
to the mower housing and fasten
with bolts and nuts (you can adjust the angle of the handle).
•
Attach the upper handle (
2)
to the lower handle (
7)
with the
supplied bolts and nuts (lever for 52G673).
•
Install the starter rope handle on the right side of the upper
handle (
2)
and pass the starter rope (
16)
through the handle.
•
Attach the control cables to the handlebar with the clips
provided (
Fig. A)
.
ATTACHING GRASS BASKET
•
Lift the rear discharge guard (
6)
.
•
Hang the grass catcher (
15)
from the rear discharge outlet using
the two catches "
a
" on the top of the mower housing (
fig. B)
.
•
Lower the rear discharge guard (
6)
.
The grass catcher is held in place by the spring force of the rear discharge
guard. The grass catcher has a convenient carrying handle to empty it of
grass clippings.
WARNING! Always make sure that the grass catcher is properly
attached.
SIDE-DISCHARGE GUARD ADJUSTMENT
•
Remove the grass catcher (
15)
and lower the rear discharge
cover (
6)
.
•
Turn the mower "on its side".
•
Install the rear discharge shutter (
17)
.
•
Pull the side discharge cover (
11)
away from the mower housing.
•
Install the side discharge shroud on the housing hooks and
release the side discharge shroud (
11)
•
Place the mower on wheels.
SETTING THE GRINDING FUNCTION
•
Remove the grass catcher (
15)
and lower the rear discharge
shield (
6)
.
•
Install the rear discharge shutter (
17)
.
•
Remove the side discharge element (if fitted) and release the
side discharge shroud (
11)
.
ADJUSTING THE CUTTING HEIGHT
The cutting height is adjusted with the cutting height lever (
14)
in 5 (or 8
for 52G673) positions from 25 - 65 mm.
•
Pull back the cutting height adjustment lever (
14)
(
fig. D)
.
•
Select the desired mowing height by moving the mowing
adjustment lever.
•
Place the cutting height adjustment lever in one of the selected
recesses of the cutting height adjustment lever lock (
14)
on the
mower housing (
fig. D)
.
WARNING! The cutting height is set simultaneously on all four road
wheels.
FILLING WITH ENGINE OIL
WARNING! Do not start the petrol mower without oil, such
starting will damage the engine.
•
Unscrew the oil filler cap (
12)
.
•
Pour in the prepared amount of oil.
•
Check the oil level on the dipstick (
12)
(
fig. E)
.
•
Screw on the oil filler plug (
12)
.
WARNING! Change the oil for the first time after 5 hours of
operation and then every 25 hours of operation. Drain the oil
into an oil-resistant container by unscrewing the oil drain plug
(19) (fig. E).
FILLING WITH GASOLINE
WARNING! Unleaded petrol with an octane number of 95
should be used as a fuel for a petrol lawn mower.
•
Unscrew the fuel filler cap (
8)
.
•
Pour gasoline into the tank and tighten the fuel filler cap (
8)
.
WARNING! After refueling, make sure the fuel filler cap is
tightened securely. Do not allow fuel to spill.
