14

EN

 Immediately switch of the machine in the
following cases:
- whenever you leave the machine,

-  before clearing blockages or unclogging

chute,

-  before checking, cleaning or working on

the machine,

-  after striking a foreign object. Inspect

the machine for damage and make
repairs before restarting and operating

the machine;

 Be careful during adjustment of the
machine to prevent entrapment of the
fingers between moving blades and fixed
parts of the machine.

Adjusting the cutting height

Fig. A, L, M

Switch off the equipment, disconnect the
plug and wait for the blade to stop. There
is a risk of injury.

Depending on the preferred cutting height, you
can adjust the wheel assembly in one of three
positions.
1.  Put the lawn mower on its side.
2.  Grasp the wheel axle on both sides.
3.   Pull evenly on the axle and insert into one of the

three notches, as shown on figure L. Ensure the
left and right side of the axle are mounted in the
same notch. Repeat this step for both axles.
Ensure the front and rear axle are mounted
in the same notch, so the lawn mower cuts
parallel to the lawn.

4.   Each notch position resembles a cutting height,

as shown on figure M.

   Position 1 resembles a cutting height of 30 mm.
   Position 2 resembles a cutting height of 50 mm.
   Position 3 resembles a cutting height of 70 mm.

Note:

 A higher cut height should be selected for

the first cut of the season.

Securing the power cord

Fig. A, N

Mount the cable into the cable strain relief (5) as
shown on figure N.

Switching the machine on/off

Fig. A, O

Do not start the mower if it is standing in
long grass.

•   To start the machine, press and hold the safety

button (3) and press the on/off switch (2).
Whilst holding the on/off switch (2), you can
release pressure on the safety button (3).

•   To stop the machine, release the on/off switch

(2) and wait until cutting blade stops rotating.

Always work your way away from the cables to
avoid cutting them, as shown on figure Q.

5. MAINTENANCE

Your mower has been designed to operate over a
long period of time with minimum of maintenance.
Continuous satisfactory operation depends upon
proper mower care and regular cleaning.

•   Keep the mower clean and dry.
•   Regularly use a blunt scraper to remove grass

and dirt from the mower

•   To clean the mower, use only mild soap and a

damp cloth. Never let any liquid get inside the
tool and never immerse any part of the tool
into liquid. Do not use any abrasive or solvent -
based cleaner.

Stop the blade(s) if the machine has to be tilted for
transportation when crossing surfaces other than
grass, and when transporting the machine to and
from the area to be used.

Do not start the machine when standing in front of
the discharge opening.

Always allow the machine to cool down before
storing.

Replace worn or damaged parts for safety. Use
only genuine replacement parts and accessories.
