 English |

29

Bosch Power Tools

F 016 L70 740 | (24.3.10)

The lawnmower can be set to 7 cutting heights
between 35 mm and 70 mm.
For this purpose, press the height of cut lever

12

inwards then lift or push down the mower until
required height is selected.
The lawnmower may be used to cut down to
20 mm by removing the blanking plate

25

 as

shown.

f

Using the height of cut between 20 – 30 mm
will shorten the battery duration.

Operation

Starting

f

The blade continues to rotate for a few sec-
onds after the machine is switched off. Al-
low the motor/blade to stop rotating before
switching “on” again.

f

Do not rapidly switch off and on.

Note:

To aid starting push handle down to lift

front wheels.
Fit the isolator key

24

.

Starting

n

Press and hold the safety button

2

.

o

Squeeze the switch lever

1

 towards

the handle.
Release the safety button

2

.

Note:

There is a short delay in the motor starting

after engaging the switch lever

1

.

Stopping

Release the switch lever

1

.

If the mower is not going to be used immediately
fit isolator key

24

 as shown in the storage posi-

tion.
The machine is fitted with a blade brake. This
safety feature stops the blade from rotating in a
few seconds.

Mowing

Protect the battery from heat, for ex-
ample continuous exposure to sun ra-
diation and fire.
Product will not function if tempera-
ture is below 0 ° C or above 45 ° C!

f

Do not leave the battery in the product in
direct sunlight.

When working

do not allow the motor to labour

particularly in heavy conditions.
When the motor labours the speed of the motor
drops and you will hear a change in the motor
sound, when this occurs stop working, release
the switch lever

1

 and

raise the height of cut

.

Failure to do so will reduce area of cut and/or
could damage the product or battery.
The grass combs

11

 allow a very close cut to the

wall or edge. Beware of running combs

11

 into

objects while cutting close to walls/edges.

Working Advice

Battery Charge-control Indication
(see main figure)

The battery

8

 is equipped with a charge-control

indicator

14

 which indicates its charge condi-

tion. The charge-control indicator

14

 consists of

3 green LEDs.
Press the button

13

 to actuate the charge-con-

trol indicator

14

. After approx. 5 seconds, the

charge-control indicator goes out automatically.
The charge condition can also be checked when
the battery is removed.

When no LED lights up after actuating the but-
ton

13

, the battery is defective and must be re-

placed.

G

1 sec

start

2

1

LED Indicators

Battery Capacity

Continuous lighting of 3
green LEDs

≥

2/3

Continuous lighting of 2
green LEDs

≥

1/3

Continuous lighting of 1
green LED

≤

1/3

Flashing of 1 green LED

Reserve

H
