The charging procedure can not be started and
the battery cannot be charged (see “Trouble-
shooting”).

Charging Advice

With continuous or several repetitive charging
cycles without interruption, the charger can
warm up. This is not meaningful and does not in-
dicate a technical defect of the battery charger.
A significantly reduced working period after
charging indicates that the battery is used and
must be replaced.

Battery Cooling (Active Air Cooling)

The fan control integrated in the battery charger
controls the temperature of the inserted bat-
tery. When the battery temperature is above
30 ° C, a fan cools down the battery to the opti-
mal charging temperature. The switched-on fan
produces a fan noise.
The battery temperature is within the optimal
charging temperature range when the fan is not
running, or the fan may possibly be defective. In
this case, the charging time of the battery ex-
tends.

Assembly

f

Do not connect the battery and/or the isola-
tor key before product is completely assem-
bled.

f

Ensure the cables are not trapped when
folding/unfolding top/bottom handles. Do
not drop the handles.

Handle assembly

n o

Insert the handle bottom

6

 into the holes

provided and secure with the screws.

Note:

The handle top

3

 is height adjustable. Fix

handles in desired position

I

 or

II

.

p

Attach the handle top

3

 with the bolts and

wing nuts

22

 to the handle bottom

6

.

Note:

Ensure that the cable clips supplied are

used to fix the cable to the handle.

Inserting the Battery

n o

Lift the battery cover latch

23

 and lift up

battery cover

7

.

p

Fit battery

8

, when correctly fitted a „click“

will be heard.

q

Fit the isolator key

24

 as shown. Ensure cor-

rect location.

r

If the mower is not going to be used immedi-

ately fit isolator key

24

 as shown in the storage

position.
Close battery cover

7

.

Removing the Battery

Lift the battery cover latch

23

 and lift up battery

cover

7

.

Remove isolator key

24

, refit in storage position.

Lift the battery cover latch

23

.

Remove the battery

8

.

Snap together the grassbox
Rotak 34/37 LI

Snap the grassbox top on the grassbox bottom
by pushing all the “snap fits” together around
the edges starting at rear and working towards
the front.

Rotak 43 LI

n

Snap the grassbox bottom halves together by

pushing all the “snap fits” together around the
edges starting at rear and working towards the
front.

o

Snap together both top and bottom half of

the grassbox.

Grassbox fitting/removing

Lift the deflector guard

5

 and hold up, fit or re-

move the grassbox

4

.

For non grass collection the mower can be used
without the grassbox

4

 in position, with the de-

flector guard

5

 in the down position.

Adjusting the Cutting Height

f

Stop, release switch lever and wait until the
motor stops before adjusting height.

The

blades continue to rotate after the machine
is switched off, a rotating blade can cause in-
jury.

f

Caution  –  do not touch the rotating blade.

For the first cutting of the season, a high cutting
height should be selected.

A

B

C

D

E

F
