Maintenance
469590_a
45
Activity
Before
each use
After
each use
After the
first 5
hours
Every 25
operating
hours
Every 50
operating
hours
Each
time
before
putting
into
storage
Checking V-belts (visual
check)
X
Cleaning the lawn tractor
(
"Rasentraktor reinigen"
)
X
Cleaning the air intake grille
on the engine
)*
X
Cleaning the transmission to
remove grass and mowing
residues (
"Rasentraktor rei-
nigen"
)
X
)*
See the instructions for use from the engine manufacturer
ADVICE
It may be necessary to shorten the maintenance intervals compared to those stated in the table
above in case of severe loading and at high temperatures.
Lubricating plan
To ensure that moving parts can move freely,
we recommend lubricating the following points at
least once a year.
Use a cloth to clean all points to be lubricated be-
fore greasing or spraying. Do not use water, so as
to avoid possible corrosion.
Lubricating points
Grease the grease nipples on the right and
left steering knuckles (21) using multi-pur-
pose grease.
Spray oil onto the bearings of the front axle
on the frame (20).
Grease the toothed segments and steering
pinion on the steering box (22) using multi-
purpose grease.
Grease the roller bearing and hub on the
front and rear axles (23) with multi-purpose
grease.
ADVICE
The front and rear wheels must be remo-
ved for greasing the axles and bearings
(
see "Radwechsel"
).
Pivoting and bearing points: Lubricate all
movable pivoting and bearing points.
Wheel change
Wheel changes are only allowed to be carried out
on firm, level ground.
1. Park the lawn tractor and remove the ignition
key.
2. Press the brake pedal (4a) fully and lock it
using the locking lever (4b).
3. Secure the lawn tractor with chocks to prevent
it from rolling away. Place the chocks under
the side that is not being raised.
4. Use suitable lifting gear (e.g. a scissor jack)
to lift the lawn tractor on the side where the
wheel should be changed. Lift the tractor until
the wheel to be changed can turn freely.
ADVICE
Take care not to bend any tractor ele-
ments when lifting. Only position the jack
on sturdy metal components.
5. Secure the lawn tractor by placing a sturdy
support (e.g. wooden block) under a sup-
porting part of the chassis so that it cannot
drop down even if the jack were to slip or tip
over.
6. Pull off the protective cap (19a).
7. Use a screwdriver to press out the lock was-
her (19b). Make sure not to lose the parts.
8. Pull off the washer (19c).
9. Pull the wheel off the axle.
