14

 | English

1 609 92A 29D | (20.7.16)

Bosch Power Tools

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-2.

Typically the A-weighted noise levels of the product are:
Sound pressure level 87 dB(A); Sound power level 98 dB(A).
Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-2:
Impact tightening of fasteners of the maximum capacity of the
tool: a

h

=10.5 m/s

2

, K = 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.

Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Assembly

Removing the Battery (see figure A)



Use only the battery chargers listed on the accessories
page.

Only these battery chargers are matched to the lith-

ium-ion battery of your power tool.

Note:

The battery supplied is partially charged. To ensure full

capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.

The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.

The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.



Do not continue to press the On/Off switch after the
machine has been automatically switched off.

The bat-

tery can be damaged.

To remove the battery

8

 press the unlocking buttons

7

 and

pull out the battery downwards.

Do not exert any force.

Observe the notes for disposal.

Cordless Impact Screwdriver

GDR 12V-110

GDS 12V-115

Article number

3 601 JE0 0..

3 601 JE0 1..

Rated voltage

V=

12

12

No-load speed

min

-1

–

–

No-load speed
– Setting 1
– Setting 2

min

-1

min

-1

0 – 1 200
0 – 2 600

0 – 1 200
0 – 2 600

Impact rate

min

-1

–

–

Impact rate
– Setting 1
– Setting 2

min

-1

min

-1

0 – 2 700
0 – 3 100

0 – 2 700
0 – 3 100

Maximum torque, hard screwdriving application
according to ISO 5393

Nm

110

115

Bolt size

mm

M4 – M12

M4 – M12

Max. screw dia.

mm

8

8

Tool holder

¼" hexagon socket



 3/8"

Weight according to EPTA-Procedure 01:2014

kg

0.92 – 1.2

0.91 – 1.2

Permitted ambient temperature
– during charging
– during operation

*

 and during storage

° C ° C

0 ... + 45

– 20 ... + 50

0 ... + 45

– 20 ... + 50

Recommended batteries

GBA 12V...

GBA 10.8V...

GBA 12V...

GBA 10.8V...

Recommended chargers

GAL 12.. CV

AL 11.. CV

GAL 12.. CV

AL 11.. CV

* limited performance at temperatures < 0 ° C
