SPECIFIC SAFETY RULES

Always observe that the lower guard is covering

the blade before placing saw down on bench or
fl oor.

An unprotected, coasting blade will cause the

saw to walk backwards, cutting whatever is in its

path.

Be aware of the time it takes for the blade to

stop after

switch is released.

DESCRIPTION

1. Lock-off button
2. Spindle lock
3. Bevel scale
4. Bevel lock knob
5. Edge guide lock knob
6. Cutting wheel
7. Base
8. Flow adjustment knob
9. Water bottle release button
10. Water bottle
11. Depth lock knob
12. Wheel wrench storage
13. Battery pack (not included)
14. Switch trigger
15. Inner wheel washer
16. Wheel
17. Outer wheel washer
18. Wheel screw
19. Incorrect method of support
20. Correct method of support

ASSEMBLY

ATTACHING GRAVITY FEED WATER BOTTLE

See Figure 2.

The gravity feed water bottle has a built in air vent that
equalizes pressure and allows water to fl ow more freely.

Remove the battery.

Unscrew the nozzle assembly.

Fill water bottle to desired level. Do not overfi ll.

Replace nozzle assembly.

Hold water bottle so that nozzle faces down.

 NOTE:

Water will not escape the bottle unless the tip

of the nozzle is depressed.

Insert the water bottle as shown. Gently press down

on the bottle until it clicks into place.
To remove water bottle, depress the water bottle

release button.

NOTE:

For dry cutting, leave water bottle installed to

prevent dust and debris from clogging the water supply
system.

CAUTION

Water bottle is designed for water only. Use of
any other fluid may cause damage to the tool.

WARNING

A   1 0 1 . 6   m m   w h e e l   i s   t h e   m a x i m u m   w h e e l
capacity of the saw. Also, never use a wheel
that is too thick to allow outer wheel washer to
engage with the flat on the spindle. Larger wheels
will come in contact with the wheel guards,
while thicker wheels will prevent wheel screw
from securing wheel on spindle. Either of these
situations could result in a serious accident.

WARNING

Do not use cutting wheels rated less than the
no load speed of this tool. Failure to heed this
warning could result in personal injury. Do not
use wheel with cracks, gaps, or teeth.

WARNING

Do not use toothed or segmented wheels. Use
only continuous rimmed diamond wheels suited
for masonry materials.

INSTALLING CUTTING WHEEL

See Figure 3.

Remove the battery pack from the saw.

Remove the wheel wrench (5 mm hex key) from the

storage area.
Depress the spindle lock button and remove the wheel

screw and outer wheel washer.

NOTE:

Turn the wheel screw clockwise to remove.

CAUTION

To prevent damage to the spindle or spindle lock,
always allow motor to come to a complete stop
before engaging spindle lock.

NOTE:

Do not run the saw with spindle lock engaged.

Wipe a drop of oil onto the inner wheel washer and

outer wheel washer where they contact the wheel.

WARNING

If inner wheel washer has been removed, replace
it before placing cutting wheel on spindle. Failure
to do so could cause an accident since wheel will
not tighten properly.

Replace the outer wheel washer.
