ENGLISH (Original instructions)
Explanation of general view
1-1. Red part
1-2. Button
1-3. Battery cartridge
2-1. Lock-off button
2-2. Switch trigger
3-1. Front hand guard
3-2. Lock
3-3. Unlock
4-1. Adjusting screw
5-1. Slightly slide
5-2. Move in the upright position
6-1. Press in
6-2. Loosen
6-3. Sprocket cover
6-4. Adjusting dial
7-1. Sprocket
8-1. Adjusting pin
9-1. Small hole
10-1. Press in
10-2. Tighten
10-3. Loosen
11-1. Lever
12-1. Press in
12-2. Loosen
13-1. Low
13-2. High
13-3. Adjusting dial
13-4. Guide bar
13-5. Saw chain
14-1. Press in
14-2. Tighten
16-1. Hook
16-2. Belt
17-1. Oil tank cap
17-2. Oil tank opening
17-3. Oil inspection window
( for refilling the tank with oil)
17-4. Oil inspection window
19-1. Lower guide
27-1. Felling area
30-1. Felling direction
30-2. Danger zone
30-3. Escape route
31-1. Scabbard (chain cover)
31-2. Battery cartridge
35-1. Small dust or particles
35-2. Slotted bit screwdriver
37-1. Sprocket
37-2. Locking ring
38-1. Locking ring
38-2. Sprocket
39-1. Limit mark
40-1. Brush holder cap
40-2. Screwdriver
SPECIFICATIONS
Model BUC250
UC250D
Chain speed per minute
8.3 m/s (500 m/min)
8.3 m/s (500 m/min)
Length of guide bar
250 mm
250 mm
Guide bar type
Sprocket nose bar
Carving bar
Sprocket nose bar
Carving bar
Type
91VG 25AP 91VG 25AP
Pitch 3/8"
1/4"
3/8"
1/4"
Saw chain
No. of drive links
40
60
40
60
Number of teeth
6
9
6
9
Overall length
576 mm
589 mm
577 mm
590 mm
Net weight
4.5 kg
4.5 kg
Rated voltage
D.C.36V
D.C.36V
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
END005-5
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･
Read instruction manual.
･
Wear eye protection.
･
Wear ear protection.
･
Wear a helmet, goggles and ear
protection.
･
Do not expose to rain.
･
Hold the saw with both hands while
working! One-handed use is extremely
hazardous!
･
Usable with the battery converter
BCV02
･
Maximum permissible cut length
･
Direction of chain travel
･
Saw chain oil adjustment
･
Only for EU countries
Do not dispose of electric equipment or
battery pack together with household
waste material!
In observance of European Directive
2002/96/EC on waste electric and
electronic equipment, 2006/66/EC on
batteries and accumulators and waste
batteries and accumulators and their
implementation in accordance with
national laws, electric equipment and
Cd
Ni-MH
Li-ion
