GENERAL SAFETY PRECAUTIONS

English

 –

 109

•

Bar groove width (inches/mm). The groove in the bar
must match the width of the chain drive links.

•

Chain oil hole and hole for chain tensioner. The bar
must be matched to the chain saw design.

(14)

Saw chain

•

Chain pitch (inches)

(13)

•

Drive link width (mm/inches)

(16)

•

Number of drive links.

(15)

Sharpening your chain and adjusting
depth gauge setting

General information on sharpening cutting teeth

•

Never use a blunt chain. When the chain is blunt you
have to exert more pressure to force the bar through
the wood and the chips will be very small. If the chain
is very blunt it will produce wood powder and no chips
or shavings.

•

A sharp chain eats its way through the wood and
produces long, thick chips or shavings.

(17)

The cutting part of the chain is called the cutter and
consists of a cutting tooth (A) and the depth gauge (B).
The cutters cutting depth is determined by the difference
in height between the two (depth gauge setting).

(18)

When you sharpen a cutting tooth there are four important
factors to remember.

1

Filing angle

(19)

2

Cutting angle

(20)

3

File position

(21)

4

Round file diameter

(22)

It is very difficult to sharpen a chain correctly without the
right equipment. We recommend that you use our file
gauge. This will help you obtain the maximum kickback
reduction and cutting performance from your chain.

See instructions under the heading Technical data for
information about sharpening your chain.

Sharpening cutting teeth

To sharpen cutting teeth you will need a round file and a
file gauge. See instructions under the heading Technical
data for information on the size of file and gauge that are
recommended for the chain fitted to your chain saw.

•

Check that the chain is correctly tensioned. A slack
chain will move sideways, making it more difficult to
sharpen correctly.

(23)

•

Always file cutting teeth from the inside face. Reduce
the pressure on the return stroke. File all the teeth on
one side first, then turn the chain saw over and file the
teeth on the other side.

(19)

•

File all the teeth to the same length. When the length
of the cutting teeth is reduced to 4 mm (5/32") the
chain is worn out and should be replaced.

General advice on adjusting depth gauge setting

When you sharpen the cutting tooth the depth gauge
setting will decrease. To maintain optimal cutting
performance the depth gauge has to be filed down to
achieve the recommended depth gauge setting. See
instructions under the heading Technical data to find the
correct depth gauge setting for your particular chain.

(24)

Adjustment of depth gauge setting

•

The cutting teeth should be newly sharpened before
adjusting the depth gauge setting. We recommend
that you adjust the depth gauge setting every third
time you sharpen the cutting teeth. NOTE! This
recommendation assumes that the length of the
cutting teeth is not reduced excessively.

•

You will need a flat file and a depth gauge tool. We
recommend that you use our depth gauge tool to
acheive the correct depth gauge setting and bevel for
the depth gauge.

•

Place the depth gauge tool over the chain. Detailed
information regarding the use of the depth gauge tool,
will be found on the package for the depth gauge tool.
Use the flat file to file off the tip of the depth gauge that
protrudes through the depth gauge tool. The depth
gauge setting is correct when you no longer feel
resistance as you draw the file along the depth gauge
tool.

(25)

Tensioning the chain

The more you use a chain the longer it becomes. It is
therefore important to adjust the chain regularly to take up
the slack.

Check the chain tension every time you refill with  saw
chain oil. NOTE! A new chain has a running-in period
during which you should check the tension more
frequently.

!

WARNING! Always wear gloves, when
working with the chain.

!

WARNING! Departure from the
sharpening instructions considerably
increases the risk of kickback.

!

WARNING! The risk of kickback is
increased if the depth gauge setting is
too large!

!

WARNING! A slack chain may jump off
and cause serious or even fatal injury.

!

WARNING! Always unplug the product
from the power supply when assembling,
checking and/or performing
maintenance.
