Rack Positions

It is important to place the wire grill into
the oven properly. Do not allow wire rack to
touch rear wall of the oven. Rack positions
are shown in the next figure. You may place
a deep tray or a standard tray in the lower
and upper wire racks.

Installing and removing wire racks

To  remove  wire  racks,  press  the  clips  shown  with  arrows  in  the  figure,

first remove the lower, and than the upper side from installation location.
To install wire racks; reverse the procedure for removing wire rack.

Replacing Oven Lamp
WARNING:

To avoid electric shock, ensure that the appliance circuit is

open before changing the lamp. (having circuit open means power is off)
First disconnect the power of appliance and ensure that appliance is cold.

Remove the glass protection by turning as  indicated in the figure on the

left  side.  If  you  have  difficulty  in  turning,  then  using  plastic  gloves  will
help you in turning.

Then remove the lamp by turning, install the new lamp with same

specifications.

Reinstall glass protection, plug the power cable of appliance into electrical

socket and complete replacement. Now you can use your oven.

Type G9 Lamp

Type E14 Lamp

Rack 4
Rack 3
Rack 2
Rack 1

220-240 V, AC
15-25 W

Figure 13

220-240 V, AC
15 W

Figure 14
