60 cm Built-In Oven Installation And Mounting

Place of use for product must be located before starting installation.
Product  mustn't  be  installed  in  places  which  are  under  the  effect  of

strong air flow.

Carry the product with minimum two people. Do not drag the product so

that floor isn't damaged.

Remove all transportation materials inside and outside the product.

Remove all materials and documents in the product.

Installation Under Counter

Cabin must match the dimensions provided in figure 2.
A clearance must be provided at the rear part of the cabin as indicated

in the figure so that necessary ventilation can be achieved.

After mounting, the clearance between lower and upper part of the

counter is indicated in figure 5 with "A". It's for ventilation and shouldn't
be covered.

Installation In An Elevated Cabinet

Cabin must match the dimensions provided in figure 4.
The clearances with the dimensions indicated in the figure must be provided

at the rear part of cabin, upper and lower sections so that necessary
ventilation can be achieved.

Installation Requirements

Product dimensions are provided in the figure 3.
Furniture surfaces for mounting and mounting materials to be used

must have a minimum temperature resistance of 100 °C.

Mounting cabin must be secured and its floor must be plane for product

not to tilt over.

Cabin floor must have a minimum strength that would handle a load of

60 kg.

Placing And Securing The Oven

Place the oven into the cabin with two or more people.
Ensure that oven's frame and front edge of the furniture match uniformly.
