31

Cleaning Oven Glass

Lift by pressing on plastic latches on left and right side as shown

in  figure  10  and  pulling  the  profile  toward  yourself  as  in  figure  11.
Glass is released after profile is removed as shown in figure 12. Remove
the released glass by pulling toward yourself carefully. Outer glass is fixed
to  oven  door  profile.  You  can  perform  glass  cleaning  easily  after  glasses
are released. You can mount glasses back by performing the operations
reversely after cleaning and maintenance are completed. Ensure that profile
is seated properly in place.

Catalytic Panel *

It is located behind the wire racks of the oven, at the right and left walls

of oven cavity. Catalytic panel removes offensive odour and provides using
your appliance at its best performance. Over time, oil and food odours
permeate into enamelled oven walls and heating elements. Catalytic panel
absorbs any food and oil odours, and burns them during cooking to clean
your oven.

Detaching catalytic panel

To remove catalytic panel; first remove the wire racks.  Once wire racks

are removed, catalytic panel will be free. It is advised to replace the
catalytic panel once every 2-3 years.

Figure 10

Figure 11

Figure 12
