30

Cleaning And Mounting Oven Door

Reversely perform respectively what you did while opening door to

reinstall oven door back.

Figure 8

Figure 8.1

Figure 8.2

Figure 9.1

Figure 9.2

Figure 9

Open the door fully

by pulling the

oven door toward

yourself. Then

perform unlock

operation by pulling

the hinge lock

upwards with the

aid of screwdriver

as indicated in

figure 8.1

.

Set the hinge lock

to the widest angle

as in

figure 8.2

.

Adjust both hinges

connecting oven

door to the oven to

the same position.

Later, close the

opened oven door

so that it will be

in a position to

contact with

hinge lock as in

figure 9.1

.

For easier removal

of oven door, when

it comes close to

closed position,

hold the cover

with two hands as

in

figure 9.2

and pull upwards.

GB
