e n g l i s h

UNPACKING

Remove all the protection elements. Check and respect

the appliance’s characteristics that appear on the

nameplate (1.1.1)

CHOICE OF LOCATION AND BUILDING IN

The diagrams show the dimensions of a cabinet that will be

able to hold your oven.

This appliance may be installed either under a worktop

(1.2.1) or in a column (1.2.2). If the cabinet is open, its

opening must be 70 mm maximum.

Your oven has optimised air circulation that allows it to

achieve remarkable cooking and cleaning results if the

following guidelines are followed :

Center the oven in the cabinet to ensure a minimum

distance of 10 mm with adjacent cabinets (1.2.3). The

material or coating of the cabinet must be heat-resistant. For

greater stability, attach the oven in the cabinet with two

screws through the holes provided for this purpose on either

side of the front inner panel.

- Drill a 2 mm diameter hole in the cabinet panel to avoid

splitting the wood.

- Attach the oven with the two screws (1.2.4) .

Tip:

To be certain that you have properly installed your

appliance, do not hesitate to call on a household

appliance specialist.

ELECTRIC CONNECTION

The appliance must be recess-fitted correctly to ensure

electrical safety.

The electrical connections are made before the appliance is

installed in its housing.

Ensure that:

- the electrical installation has sufficient voltage,

- the electrical wires are in good condition,

- the diameter of the wires complies with the installation

requirements.

During maintenance operations, the appliance must be

unplugged from the electrical grid; fuses must be switched

off or removed.

Warning:

The safety wire (green-yellow) is connected to the

appliance’s

terminal and must be connected to the

earth terminal of the electrical set-up.

The fuse in your set-up must be 16 amperes.

If the electrical installation in your residence requires

any changes in order to hook up your appliance, call

upon a professional electrician. If the oven malfunctions

in any way, unplug the appliance or remove the fuse

corresponding to the sector where the oven is hooked

up.

No pyrolysis ovens:

The appliance must be connected to the mains with a red

single-phase connection with the neutral (blue) connection

guaranteed (1.3.1). Fit the oven into the space, ensuring

there is no excess cable in the upper part.

Screw it to the setting using the two screws supplied.

1.1

1.2

1.3

Installation

1
