14

 | Français

Impact drilling

Set the selector switch

(4)

 to the "impact

drilling" symbol.
The selector switch

(4)

 clicks into place and

can also be actuated when the motor is running.

Switching on/off

To

start

 the power tool, press and hold the on/off switch

(6)

.

Press the lock-on button

(5)

 to

lock

 the on/off switch

(6)

 in

this position.
To

switch off

 the power tool, release the on/off switch

(6)

;

or, if the switch is locked with the lock-on button

(5)

, briefly

press the on/off switch

(6)

 and then release it.

Adjusting the Speed/Impact Rate

You can adjust the speed of the power tool when it is on by
pressing in the on/off switch

(6)

 to varying extents.

A light pressure on the on/off switch

(6)

 results in a low rota-

tional speed. Increased pressure on the switch causes an in-
crease in speed.

Preselecting the Speed/Impact Rate (not applicable to
tool model 3 601 B17 103)

You can preselect the required speed/impact rate using the
speed preselection thumbwheel

(7)

, even during operation.

The required speed/impact rate is dependent on the mater-
ial and the work conditions and can be determined by prac-
tical trials.

Practical Advice

u

Pull the plug out of the socket before carrying out any
work on the power tool.

u

Only apply the power tool to the screw/nut when the
tool is switched off.

 Rotating tool inserts can slip off.

After working at a low speed for an extended period, you
should operate the power tool at the maximum speed for ap-
proximately three minutes without load to cool it down.
To drill into tiles, set the selector switch

(4)

 to the "drilling"

symbol. After drilling through the tile, set the selector switch
to the "impact drilling" symbol and drill with impact.
Use carbide drill bits when working with concrete, stone and
masonry.
When drilling into metal, only use sharpened HSS drills (HSS
= high-speed steel) which are in perfect condition. The

Bosch

 accessory range guarantees appropriate quality.

Using the drill bit sharpener (accessory), you can effortlessly
sharpen twist drill bits with a diameter of 2.5–10 mm.

Maintenance and Service

Maintenance and Cleaning

u

Pull the plug out of the socket before carrying out any
work on the power tool.

u

To ensure safe and efficient operation, always keep
the power tool and the ventilation slots clean.

In order to avoid safety hazards, if the power supply cord
needs to be replaced, this must be done by

Bosch

 or by an

after-sales service centre that is authorised to repair

Bosch

power tools.

After-Sales Service and Application Service

Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. You can find explosion drawings and information on
spare parts at:

www.bosch-pt.com

The Bosch product use advice team will be happy to help you
with any questions about our products and their accessor-
ies.
In all correspondence and spare parts orders, please always
include the 10‑digit article number given on the nameplate
of the product.

Great Britain

Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange
the collection of a product in need of servicing or repair.
Tel. Service: (0344) 7360109
E-Mail: boschservicecentre@bosch.com

You can find further service addresses at:

www.bosch-pt.com/serviceaddresses

Disposal

The power tool, accessories and packaging should be re-
cycled in an environmentally friendly manner.

Do not dispose of power tools along with
household waste.

Only for EU countries:

According to the European Directive 2012/19/EU on Waste
Electrical and Electronic Equipment and its implementation
into national law, power tools that are no longer usable must
be collected separately and disposed of in an environment-
ally friendly manner.

Français

Consignes de sécurité

Avertissements de sécurité généraux pour l’outil
électrique

AVERTISSE-

MENT

Lire tous les avertissements de sé-
curité, les instructions, les illustra-
tions et les spécifications fournis
