12

 | English

Intended Use

The power tool is intended for impact drilling in brick, con-
crete and stone, as well as for drilling in wood, metal,
ceramic and plastic. Tools with electronic control and right/
left rotation are also suitable for screwdriving and thread
cutting.

Product Features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

Keyless chuck

A)

(2)

Front sleeve

(3)

Rear sleeve

(4)

"Drilling/impact drilling" selector switch

(5)

Lock-on button for on/off switch

(6)

On/off switch

(7)

Speed preselection thumbwheel
(not applicable to tool model 3 601 B17 103)

(8)

Rotational direction switch

(9)

Button for depth stop adjustment

(10)

Wing bolt for auxiliary handle adjustment

(11)

Auxiliary handle (insulated gripping surface)

A)

(12)

Depth stop

A)

(13)

Drill chuck key

A)

(14)

Keyed chuck

A)

(15)

Universal bit holder

A)

(16)

Screwdriver bit

A)

(17)

Hex key

A)

(18)

Open-ended spanner

B)

(19)

Handle (insulated gripping surface)

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

B)

Commercially available (not included in the scope of deliv-
ery)

Technical Data

Impact drill

GSB 13 RE

Article number

3 601 B17 1..

Rated power input

W

600

Max. power output

W

301

No-load speed

min

-1

0 – 2800

Rated speed

min

-1

1570

Impact rate

min

-1

44800

Rated torque

Nm

1.8

Clockwise/anti-clockwise ro-
tation

●

Spindle collar diameter

mm

43

Max. drilling diameter

Impact drill

GSB 13 RE

– Masonry

mm

15

– Concrete

mm

13

– Steel

mm

10

– Wood

mm

25

Chuck capacity

mm

1.5 – 13

Weight according to
EPTA-Procedure 01:2014

kg

1.8

Protection class

 / II

The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.

Noise/vibration information

Noise emission values determined according to

EN 62841-2-1

.

Typically, the A-weighted noise level of the power tool is:
Sound pressure level

97

 dB(A); sound power level

108

 dB(A). Uncertainty K =

5

 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 62841-2-1

:

Drilling into metal: a

h

 =

4

 m/s

2

, K =

1.5

 m/s

2

,

Impact drilling into concrete: a

h

 =

18.5

 m/s

2

, K =

3

 m/s

2

,

Screwdriving: a

h

<2.5

 m/s

2

, K =

1.5

 m/s

2

.

The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure and may be used to com-
pare power tools. They may also be used for a preliminary
estimation of vibration and noise emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the
power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly
increase the vibration and noise emissions over the total
working period.
To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping their hands warm,
and organising workflows correctly.

Assembly

u

Pull the plug out of the socket before carrying out any
work on the power tool.

Auxiliary Handle (see figure A)

u

Do not operate your power tool without the auxiliary
handle

(11)

.
