12

 | English

1 609 92A 186 | (7.4.15)

Bosch Power Tools

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for drilling in wood, metal, ceramic
and plastic. Machines with electronic control and right and
left rotation are also suitable for screwdriving and tapping.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Key type drill chuck

2

Rotational direction switch

3

On/Off switch

4

Lock-on button for On/Off switch

5

Auxiliary handle (insulated gripping surface)

6

Chuck key

7

Handle (insulated gripping surface)

8

Screwdriver bit *

9

Universal bit holder *

10

Securing screw for key type drill chuck

11

Hex key *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-1.

Typically the A-weighted noise levels of the product are:
Sound pressure level 84 dB(A); Sound power level 95 dB(A).
Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-1:

Drilling into metal: a

h

= 3.5 m/s

2

, K = 1.5 m/s

2

Screwdriving without impact: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

Tapping: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, until
19 April 2016: 2004/108/EC, from 20 April 2016 on:
2014/30/EU, 2006/42/EC including their amendments and
complies with the following standards: EN 60745-1,
EN 60745-2-1.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 07.04.2015

Rotary drill

GBM 13 HRE

Article number

3 601 K49 6A.

Rated power input

W

550

Output power

W

285

No-load speed

min

-1

0 – 550

Rotational speed under load,
max.

min

-1

450

Rated torque

Nm

5

Spindle collar dia.

mm

43

Max. drilling dia.

– Steel
– Wood
– Aluminium

mm
mm
mm

13
40
20

Chuck clamping range

mm

1.5 – 13

Weight according to
EPTA-Procedure 01/2003

kg

2.1

Protection class

/

II

The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9
