15

•

Before assembling or removing nozzles ensure that

the device is unplugged.

• Maximum time of continuous use of the device with a

whisk, chopper, grinding, grater and cubic attachment must

not exceed 1 minute, then you should turn off the blender

for 3 minutes.
• Maximum time of continuous use of the device with a

whisk must not exceed 10 minutes, then you must turn off

the blender for 30 minutes.

ORDER OF OPERATION:

1.

   Assemble the necessary attachment with the de

-

vice as described above.

2.

   Plug in the device.

3.

   Select the required speed by setting its speed

switch. The blender has a smooth speed control

(from low speed to high.) Then press and hold the

on / off button.

4.

   You can also turn on the blender by holding down

the

TURBO

 Mode. In this case, the device will

operate at maximal speed all the time. The speed

will not change even if you change the position of

the switch.

5.

   To switch off, release the

TURBO

 Mode.

6.

   Unplug the power cord from the outlet.

7.

   Remove the motor unit.

ELEMENTS OF DESIGN,

Рiс. В

Speed Switch

On / Off button

TURBO

 Mode button

Motor unit

Puree attachment

Whisk

Multifunctional glass cup XL

Cup’s lid

Pusher

Working console

Chopping disk

Grater disk

Grinding blade

Opening for motor unit installation

Cubic cutting attachment

Cleaning attachment

Measuring cup

UTILIZATION,

Рiс. C

Whisk.

Used  for  whipping  egg  whites,  creams,  biscuit  dough,

dough for pancakes, stirring desserts.

•  Insert the motor unit in the attachment and turn it

clockwise until it stops.

Pic.C-1.

•  Dip the whisk in a bowl with ingredients and turn on

the blender.

NOTE!

  For  best  results,  whisk  at  a  low  speed,  than

raise  the  speed.  Whisk  ingredients  in  small  portions  –

no more than 4 egg whites at once.

Puree attachment.

Used for soups-purees, baby food, pies and sauces.

•  Insert the motor unit to the attachment and turn coun-

terclockwise until it stops.

Рiс.C-1.

Multifunctional glass cup XL.

Used for installing chopping and grater disks and stain

-

less steel blades.

•  Place the cup on a dry and flat surface.

•   Install the required attachment as shown in the

Рiс.

C-2.

Chopping disk.

Used to cut ingredients in small slices.

•  Install the cup into the working console.

• Install onto the console the chopping disk, selecting

small or large slices.

•  Close  the  cup  with  the  lid,  using  special  clips  on  the

lid’s sides.

The blades are very sharp, be careful.

11

15

12

16

13
14

• Install the motor unit into the special opening on the

cup’s lid.

Grater disks.

Used for grating ingredients.

•  Install the cup into the working console.

•  Install onto the console the grater disk, selecting small

or large grater.

•  Close  the  cup  with  the  lid,  using  special  clips  on  the

lid’s sides.

• Install the motor unit into the special opening on the

cup’s lid.

Cubic cutting attachment, Рiс.C-3

Used for cutting boiled/fresh vegetables and fruits into

cubes.

• Install the attachment   into the cup

.

•  Close  the  cup  with  the  lid,  using  special  clips  on  the

lid’s sides

• Install the motor unit into the special opening on the

cup’s lid.

Grinding blade.

Used  for  the  preparation  of  baby  food,  mince,  chop

-

ping,  nuts,  making  pates,  butter  with  additions,  chop

-

ping  onions,  garlic  and  etc.  Grinding  blade  is  not  in

-

tended for liquid foods.

•  Install grinding blade into the cup.

•  Close  the  cup  with  the  lid,  using  special  clips  on  the

lid’s sides

• Install the motor unit into the special opening on the

cup’s lid.

Before first use,

 wipe the motor unit with a dry cloth.

Wash the cup, lid, pusher and attachments in a worm water

with some detergents. The time when the device idles must

not exceed 15 seconds.

Puree attachment

 .....................................................1 p c .

Whisk

 ........................................................................1 p c .

Multifunctional cup XL, 1,2L ..................................... 1 p c .

Cup’s lid ....................................................................1 p c .

Pusher

 ......................................................................1 p c .

Working console

 .......................................................1 p c .

Grinding blade ..........................................................1 p c .

Cubic cutting attachment ..........................................1 p c .

Cleaning attachment.................................................1 p c .

Stainless steel chopping disk

 ................................... 1 p c .

Stainless steel grater disk

.........................................1 p c .

Measuring cup

 ..........................................................1 p c .

Instructions manual

 ..................................................1 p c .
