16

 | English

Product description and
specifications

Read all safety warnings and all instruc-
tions.

 Failure to follow the safety warnings and

instructions may result in electric shock, fire
and/or serious injury.

Please observe the illustrations at the ending of this operat-
ing manual.

Intended Use

The power tool is intended for sawing wood such as wooden
beams, planks, branches, tree trunks, etc., and for sawing of
trees. Cuts can be sawed with or across the grain.
This power tool is not suitable for sawing mineral materials.

Delivery Scope

Carefully remove the machine from its packaging and check
if the following parts are complete:
– Chain saw
– Saw chain
– Chain bar
– Chain guard
– Operating instructions
When parts are missing or damaged, please contact your
dealer.

Product Features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

Rear handle

(2)

On/Off switch

(3)

Front handle

(4)

Hand Guard/Activation lever for kickback brake

(5)

Serial number

(6)

Nose sprocket

(7)

Chain guard

(8)

Saw chain

(9)

Chain bar

(10)

Gripping teeth

(11)

Chain-tensioning ring

(12)

Clamping knob

(13)

Cover

(14)

Oil filler cap

(15)

Lock-off button for On/Off switch

(16)

Mains plug

A)

(17)

Extension cable

B)

(18)

Symbol for rotation and cutting direction

(19)

Drive sprocket

(20)

Fastening bolt

(21)

Oil seal

(22)

Oil outlet

(23)

Guide fin for chain bar

(24)

Chain catch bolt

(25)

Affixed tension wheel

(26)

Oil viewing window

A)

country specific

B)

The accessories illustrated or described are not included as
standard delivery.

Technical Data

Chain saw

UniversalChain 35

UniversalChain 40

Article number

3 600 HB8 1.0

3 600 HB8 1.1

Rated power input

W

1800

1800

Chain speed (no-load)

m/s

12

12

Blade length

cm

35

40

Chain type

3/8"–90

3/8"–90

Drive link thickness

mm

1.1 (0.043")

1.1 (0.043")

Amount of drive links

52

57

Oil reservoir capacity

ml

250

250

Automatic chain oiler

●

●

Toolless chain tensioning (SDS)

●

●

Nose sprocket

●

●

Kickback Brake

●

●

Run-on Brake

●

●

Gripping teeth

●

●

Weight according to EPTA‑Procedure 01:2014

kg

4.2

4.3

Protection class

 / II

 / II

F 016 L81 829 | (28.11.2019)
