ENG

2.1 Multimedia Speaker System

20

–

–

+

d

d

e

f

g

h

c

a

b

i

l

k

n

p

o

m

j

1

2

3

4

5

6

9

8

7

+

T U NE

-

T UNE +

C

H+

C

H

-

S

A

E

V

A

O

UT

VOL

EQ

MUTE

AUX

USB

FM

SD

0

R

ESET

R

EPE

A

T

Fig. 3. Remote control

l

CH+/

: next track

(pressed short in the Player mode)

next station

*

(pressed short in the Tuner mode)

m

AUTO:  start  auto  scanning  and  memorizing  stations  in  FM

band (in the Tuner mode)

n

 VOL+/-:

volume control

o

 SAVE: memorize selected frequency

(in the Tuner mode)

p

RESET: return to default settings

Note. Before operating insert the batteries (included) into

the remote control.

*

The  frequencies  are  switched  if  there  are  stations  preset  in  the

memory.

**

The storage device must be formatted as FAT, FAT32. Memory cards

SDHC  class  10  or  less  can  be  used.  Connecting  devices  other  than

USB  flash  drive  is  not  recommended.  Connection  of  HDDs  and  other

devices can cause damage to the MSS.

5. PREPARATION AND OPERATION

Speaker placement

•

Place the speakers symmetrically to the listener at least one me-

ter

away.  The  subwoofer  emits  non-directional  sound,  therefore  it

can be located in any place of the room where it sounds the best.

•

Place  MSS  far  away  from  monitors  and  TV  sets,  as  insignificant

image distortion in these supersensitive devices is possible.

Installation and operation

MS-1820 speaker system can be connected to virtually any audio

devices: DVD/CD players, PCs, laptops, etc. (see diagram in Fig. 4).

Warning!  Before  connection  all  components  of  the  system

must be turned off.

•

Connect  satellites  with  the  subwoofer  using  built-in  acoustic  cables  in  speakers.  Connect  the  left

speaker  to  the  OUTPUT  L

o

  jack  and  the  right  speaker  to  the  subwoofer  OUTPUT  R

n

  jack  (see

diagram  in Fig. 4).

•

To connect the MSS to a PC, МР3/CD player, use a 2RCA to mini-jack signal cable (included).

Insert the RCA jacks of the signal cable into the

L

l

 and R

m

 jacks of the

INPUT

, and the mini-jack

of the signal cable – into the LINE OUT port of your PC sound card or an audio output of your МР3/

CD player.

•

To connect the MSS to a TV or DVD/CD player, use a

2RCA to 2RCA signal cable (not included)

.

Insert the RCA jacks of the signal cable into the

L

l

 and R

m

 jacks of the

INPUT

, and the other RCA

jacks – into your TV or DVD/CD player audio output jacks, as shown in Fig. 4.

Note. Check the reliable fixation of wires in the terminals, polarity of connection and absen-

ce of contact of the bared wires with each other and the metal parts of the hardware.
