23

ENGLISH

TECHNICAL PASSPORT

Cooker hood

INSTALLATION

The minimum distance between

the supporting surface for the cooking

equipment on the hob and the lowest

part of the range hood must be not less

than 45cm from electric cookers and

50cm from gas or mixed cookers.

If the instructions for installation for

the gas hob specify a greater distance,

this must be adhered to.

ELECTRICAL CONNECTION

The mains power supply must cor-

respond to the rating indicated on the

plate situated inside the hood. If pro-

vided with a plug connect the hood to a

socket in compliance with current regu-

lations and positioned in an accessible

area, after installation. If it not fitted

with a plug (direct mains connection)

or if the plug is not located in an ac-

cessible area, after installation, apply a

double pole switch in accordance with

standards which assures the complete

disconnection of the mains under con-

ditions relating to overcurrent category

III, in accordance with installation in-

structions.

WA R N I N G!

 Before re-connecting

the hood circuit to the mains supply and

checking the efficient function, always

check that the mains cable is correctly

assembled. The hood is provided with a

special power cable; if the cable is dam-

aged, request a new one from Technical

Service.

MOUNTING

Very heavy product; hood handling

and installation must be carried out by
at least two persons.

Before beginning installation:

Â

Check that the product purchased

is of a suitable size for the chosen
installation area.

Â

Remove the charcoal (*) filter/s if

supplied (see also relative paragraph).
This/these is/are to be mounted only if

you want lo use the hood in the filtering

version.

Â

Check (for transport reasons)

that there is no other supplied material
inside the hood (e.g. packets with
screws (*), guarantees (*), etc.), eventually
removing them and keeping them.

Â

If possible, disconnect and move

freestanding or slide-in range from
cabinet opening to provide easier

access  to  rear  wall/ceiling.  Otherwise

put a thick, protective covering over
countertop, cooktop or range to protect

from  damage  and  debris.  Select  a  flat

surface for assembling the unit. Cover
that surface with a protective covering
and place all canopy hood parts and
hardware in it.

Â

In addition check whether near

the installation area of the hood (in
the area accessible also with the hood
mounted) an electric socket is available
and it is possible to connect a fumes
discharge device to the outside (only
suction version).

Â

Carry out all the masonry work

necessary (e.g. installation of an electric
