8

TECHNICAL PASSPORT

ENGLISH

Integrated extractor hood SLIMLUX II

Моdel

SLIMLUX II

50

SLIMLUX II

60

SLIMLUX II

90

Моtor

Voltage (V)

230

230

230

Frequency (Hz)

50

50

50

Rated power (W)

255

255

255

Exhaust Capacity

Free Outlet (m./h)

540

540

540

Maximal capacity (m./h)

366

366

366

1st Speed

233

233

233

2nd Speed

332

332

332

Sound Level (standard) EN-60704-2-13 (dBA)

1st Speed

56

56

56

2nd Speed

65

65

65

6. CONTROLLER TYPES AND USE

By pressing the button shown in the

fi gure 1, you will be able to control the

functions of the extractor.

Two achieve better extraction, we

recommend switching on the extractor

a few minutes before starting to cook

(3  -  5  minutes)  so  that  the  air  fl ow  is

continuous and stable when extracting

the fumes.

Likewise, keep the extractor

switched on for a few minutes when

cooking is complete to allow all fumes

and odours to be expelled.

6.1. Control Panel

A

Motor push control that allow 3

speeds to be selected:

Low

 High

 Intensive

B

Light push control that allow 3

positions to be selected

    On

0   Off
A Automatic
C

Lighting by means of lamps

D  Filters located over cooking

area, easily withdrawn for cleaning

E

Extractable group that allows a

greater gas capture area

F  Possibility of incorporating

activated charcoal fi lter (Fig. 2)

G-H  Anti return tabs to be located

in the outlet mouth, locating their ends
in the holes provided (Fig.2).
