11

ENGLISH

Cooker hood

TECHNICAL PASSPORT

USE

The hood is designed to be used ei-

ther for exhausting or filter version.

DUCTING VERSION

In this case the fumes are conveyed

outside of the building by means of a

special pipe connected with the con-

nection ring located on top of the hood.

Attention! The exhausting pipe is

not supplied and must be purchased

apart.

Diameter of the exhausting pipe

must be equal to that of the connection

ring.

In the horizontal runs the exhaust-

ing pipe must be slightly slanted (about

10°) and directed upwards to vent the

air easily from the room to the outside.

Attention! If the hood is supplied

with  active  charcoal  filter,  then  it  must

be removed.

Connect the hood and discharge

holes on the walls with a diameter

equivalent to the air outlet (connection

flange).

Using the tubes and discharge holes

on walls with smaller dimensions will

cause a diminution of the suction per-

formance and a drastic increase in noise.

Any responsibility in the matter is

therefore declined.

!

   Use a duct of the minimum indis-

pensible length.

!

   Use a duct with as few elbows as

possible (maximum elbow angle:

90°).

!

   Avoid drastic changes in the duct

cross-section.

!

   Use a duct as smooth as possible

inside.

!

   The duct must be made of certi-

fied material.

FILTER VERSION

One  active  charcoal  filter  is  needed

for this and can be obtained from your

usual retailer.

The  filter  removes  the  grease  and

smells from the extracted air before

sending it back into the room through

the upper outlet grid.

INSTALLATION

The minimum distance between

the supporting surface for the cooking

equipment on the hob and the lowest

part of the range hood must be not less

than 45cm from electric cookers and

50cm from gas or mixed cookers.

If the instructions for installation for

the gas hob specify a greater distance,

this must be adhered to.

ELECTRICAL CONNECTION

The mains power supply must corre-

spond to the rating indicated on the plate

situated inside the hood. If provided with

a plug connect the hood to a socket in

compliance with current regulations and

positioned in an accessible area, after

installation.  If  it  not  fitted  with  a  plug

(direct mains connection) or if the plug

is not located in an accessible area, after

installation, apply a double pole switch

in accordance with standards which as-

sures the complete disconnection of the

mains under conditions relating to over-

current category III, in accordance with

installation instructions.

Â

Warning!

 Before re-connecting

the hood circuit to the mains supply

and  checking  the  efficient  function,  al

-

ways check that the mains cable is cor-

rectly assembled. The hood is provided

with a special power cable; if the cable
