23

EN

reset of the filter saturation indicator; repeat the operation if necessary (for ex., when both filters are saturated).

Activation of the charcoal filter saturation indicator

The saturation indicator of the charcoal filter is normally disabled. To activate it, proceed in the following manner:

With the display on (ON) and the suction off (OFF), press simultaneously the buttons

T8

 and

T9

 for more than 3 seconds; the button

T9

 lights on with steady light for approx. 5 seconds, to indicate the activation.

To disable it, repeat the operation; the button

T9

 will flash for approx. 5 seconds to indicate the disabling.

 Buttons

T8

 and

T9

 are not visible at this stage (on some models). They are visible only as described

in operation section of the manual.

Approximate distance of button

T8

 from

T7

 is 16 mm, and distance of button

T9

 from

T8

 is 26 mm.

Setting of Automatic Operation parameters

For correct use of the automatic operation, perform „Hood Calibration”.

Hood Calibration

With the display on (ON) and the suction off (OFF), press button

T3

 for 3 seconds.

The suction speed (power) 2 starts functioning and button

T3

 flashes to indicate that hood calibration is initiated and it will last for approx.

15 minutes.

Note:

 to interrupt the calibration, press

T3

 for 5 seconds; the calibration will be invalidated and should therefore be repeated.

WHT643E4XBG, WHT943E4XBG, WHT633E2X, WHT633E2X, WHT923E5X, WHT623E3XBG, WHT923E3XBG,

WHT623E5XUK, WHT923E5XUK, WHT923E3XBGUK

To select the functions of the hood, simply touch the controls.

T1.

  Stand by/ON display

T2.

  ON/OFF suction speed (power) 1

T3.

  ON/OFF suction speed (power) 2

T4.

  ON/OFF suction speed (power) 3

T5.

  ON/OFF lights

MAINTENANCE

ATTENTION! Before performing any maintenance operation, isolate the hood from the electrical supply by switching off at the

connector and removing the connector fuse.

Or if the appliance has been connected through a plug and socket, then the plug must be removed from the socket.

Cleaning

The cooker hood should be cleaned regularly (at least with the same frequency with which you carry out maintenance of the fat filters) inter

-

nally and externally. Clean using the cloth dampened with neutral liquid detergent. Do not use abrasive products.

DO NOT USE ALCOHOL!

WARNING:

 Failure to carry out the basic cleaning recommendations of the cooker hood and replacement of the filters may cause fire risks.

Therefore, we recommend observing these instructions.

The manufacturer declines all responsibility for any damage to the motor or any fire damage linked to inappropriate maintenance or failure

to observe the above safety recommendations.

Grease filter

Traps cooking grease particles.

The grease filter

 must be cleaned once a month using non aggressive detergents, either by hand or in the dishwasher, which must be

set to a low temperature and a short cycle. When washed in a dishwasher, the grease filter may discolour slightly, but this does not affect

its filtering capacity.

To remove the grease filter, pull the spring release handle.

T7

T8

T9

16 mm

26 mm

T1.

  ON/OFF lights

T2.

  OFF suction speed (power)

T3.

  ON suction speed (power) 1

T4.

  ON suction speed (power) 2

T5.

  ON suction speed (power) 3

T1

T2

T3

T4

T5

T1

T2

T3

T4

T5
