21

EN

Mounting

Very heavy product; hood handling and installation must be carried out by at least two persons.

Before beginning installation:

•  Check that the product purchased is of a suitable size for the chosen installation area.

•

Remove the charcoal (*) filter/s if supplied (see also relative paragraph). This/these is/are to be mounted only if you want lo use the

hood in the filtering version.

•  Check (for transport reasons) that there is no other supplied material inside the hood (e.g. packets with screws (*), guarantees (*), etc.),

eventually removing them and keeping them.

•  If possible, disconnect and move freestanding or slide-in range from cabinet opening to provide easier access to rear wall/ceiling.

Otherwise put a thick, protective covering over countertop, cooktop or range to protect from damage and debris. Select a flat surface

for assembling the unit. Cover that surface with a protective covering and place all canopy hood parts and hardware in it.

•  In addition check whether near the installation area of the hood (in the area accessible also with the hood mounted) an electric socket

is available and it is possible to connect a fumes discharge device to the outside (only suction version).

•  Carry out all the masonry work necessary (e.g. installation of an electric socket and/or a hole for the passage of the discharge tube).

Expansion wall plugs are provided to secure the hood to most types of walls/ceilings. However, a qualified technician must verify suitability

of the materials in accordance with the type of wall/ceiling. The wall/ceiling must be strong enough to take the weight of the hood.

Do not

tile, grout or silicone this appliance to the wall. Surface mounting only.

OPERATION

Use the high suction speed in cases of concentrated kitchen vapours. It is recommended that the cooker hood suction is switched on for

5 minutes prior to cooking and to leave in operation during cooking and for another 15 minutes approximately after terminating cooking.

WHT953S1XBG, WHT653S1XBG

To select the functions of the hood press on the symbol. Function will be activated when symbol will be released.

T1. Standby

 mode (the control panel off – all functions disabled) /

ON

 (control panel switched on)

Note:

 After about a minute of inactivity (suction and lights), the hood will automatically switch to standby.

T2.  ON/OFF lights

- with the lights on, touch the LED strip

SL1

 with the fingers towards right or left to increase or decrease the intensity of the light.

Note:

 the light turns on at the last set intensity before its switching off.

T3.  ON/OFF Automatic operation “AdaptTech”.

  The hood automatically sets the suction speed (power)

2

 to increase if the environmental conditions detected by the hood sensor

require it.

If there are no variations in the environmental conditions, after 10 minutes (if the hood is already in suction speed (power) 1), the hood

turns off.

Note:

 for a correct use of this function, first perform the

„Setting of the parameters for Automatic Operation”

 (see corresponding

paragraph).

Note:

 During automatic operation, if the user acts on the other functions that adjust the speed, auto ventilation function is switched off.

T4.  ON/OFF Motor

- with the motor running, touch the led strip

SL2

 with your fingers towards right or left to increase or decrease the suction speed (pow

-

er).

Note:

 the motor starts running at the last suction speed (power) set before switching off.

T5.  ON/OFF Intensive suction

 speed (power)

“POWER BOOST”

 (timed)

Note:

 After 5 minutes of operation the hood returns to its previous state.

T6.  ON/OFF intensive suction speed (power)

“POWER BOOST x 2”

 (timed)

Note:

 After 5 minutes of operation, the hood goes back to the previous status.

T7. ON/OFF

 operation mode

 „ReFresh”.

Every 50 minutes of inactivity, the suction speed (power

1

 is turned on for 10 minutes.

T8.  ON/OFF Timer

 of the suction speed (power).

Note:

 this function is available for the speeds that can be selected with button

T4

.

Press once or repeatedly to choose the delayed switch off time that you want to set (10-20-30 minutes)

T9.  Indicator and reset filter saturation

The button lights on automatically with steady light when it is necessary to perform the grease filter maintenance.

The button lights on automatically with flashing light when it is necessary to perform the charcoal filter maintenance.

T1

T2

T3

T4

T5

T6

T7

T8

T9

SL1

SL2
